TGM2CB-24VAC

Active

R-K Electronics, Inc.

RELAY TIME DELAY 10HR 3A 240V

Search across all available documentation for this part.

Active

R-K Electronics, Inc.

RELAY TIME DELAY 10HR 3A 240V

Technical Specifications

Parameters and characteristics commom to parts in this series

RELAY TIME DELAY 10HR 3A 240V

Part	Timing Initiate Method	Circuit	Voltage - Supply	Mounting Type	Function	Termination Style	Contact Rating @ Voltage	Delay Time [Min]	Delay Time [Max]	Relay Type	Timing Adjustment Method
R-K Electronics, Inc. TGM2CB-120VAC	Input Voltage	DPDT (2 Form C)	120 VAC	Socketable	On-Delay	Plug In	3 A, 30 VDC, 240 VAC	0.1 Sec	10 Hrs	Mechanical Relay	Hand Dial
R-K Electronics, Inc. TGM2CB-24VAC	Input Voltage	DPDT (2 Form C)	24 VAC	Socketable	On-Delay	Plug In	3 A, 30 VDC, 240 VAC	0.1 Sec	10 Hrs	Mechanical Relay	Hand Dial

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

On-Delay Time Delay Relay DPDT (2 Form C) 0.1 Sec ~ 10 Hrs Delay 3A @ 240VAC/30VDC Socketable
