TS-116-G-A

Active

Samtec Inc.

CONNECTOR, HEADER, 16POS, 1ROW, 2.54MM

Search across all available documentation for this part.

Active

Samtec Inc.

CONNECTOR, HEADER, 16POS, 1ROW, 2.54MM

Technical Specifications

Parameters and characteristics for this part

Part	Color	Pitch [x]	Pitch [x]	Mounting Type	Connector Type	Contact Finish	Contact Finish Thickness	Contact Finish Thickness	Termination	Number of Positions	Number of Rows
Samtec Inc. TS-116-T-A-1	Black	2.54 mm	0.1 in	Through Hole	Header	Tin	200 Áin	5.08 Ám	Solder	16	1
Samtec Inc. TS-116-G-AA	Black	2.54 mm	0.1 in	Through Hole	Header	Gold	20 µin	0.51 µm	Solder	16	1
Samtec Inc. TS-116-G-A	Black	2.54 mm	0.1 in	Through Hole	Header	Gold	20 µin	0.51 µm	Solder	16	1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

16 Position Header Connector Post Gold
