Technical Specifications
Parameters and characteristics for this part
| Specification | 6504FE 0041000 |
|---|---|
| Cable Type | Multi-Conductor |
| Conductor Insulation | Low Smoke Poly-Vinyl Chloride (LSPVC) |
| Conductor Material | Copper, Bare |
| Conductor Strand [custom] | 7 |
| Conductor Strand [custom] | 30 AWG |
| Features | Rip Cord, Drain Wire |
| Jacket (Insulation) Diameter [diameter] | 4.45 mm |
| Jacket (Insulation) Diameter [diameter] | 0.175 in |
| Jacket (Insulation) Material | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum |
| Jacket (Insulation) Thickness | 0.015 in |
| Jacket (Insulation) Thickness | 0.381 mm |
| Jacket Color | Yellow |
| Length | 1000 ft |
| Length | 304.8 m |
| Number of Conductors | 6 |
| Operating Temperature [Max] | 75 ░C |
| Operating Temperature [Min] | 0 °C |
| Ratings | UL Style CMP |
| Shield Coverage | 100 % |
| Shield Material | Aluminum |
| Shield Type | Foil |
| Usage | Sound, Security, Alarm |
| Voltage | 300 V |
| Wire Gauge | 22 AWG |
6504FE Series
| Part | Shield Type | Number of Conductors | Length | Length | Shield Material | Usage | Voltage | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Wire Gauge | Conductor Material | Jacket (Insulation) Material | Ratings | Conductor Insulation | Jacket Color | Shield Coverage | Cable Type | Operating Temperature [Max] | Operating Temperature [Min] | Features | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Conductor Strand [custom] | Conductor Strand [custom] | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Belden Inc. | Foil | 6 | 1000 ft | 304.8 m | Aluminum | Alarm Security Sound | 300 V | 0.015 in | 0.381 mm | 22 AWG | Copper Bare | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | UL Style CMP | Low Smoke Poly-Vinyl Chloride (LSPVC) | Yellow | 100 % | Multi-Conductor | 75 ░C | 0 °C | Drain Wire Rip Cord | 4.45 mm | 0.175 in | 7 | 30 AWG | ||
Belden Inc. | Foil | 6 | 1000 ft | 304.8 m | Aluminum | Alarm Security Sound | 300 V | 0.015 in | 0.381 mm | 22 AWG | Copper Bare | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | UL Style CMP | Low Smoke Poly-Vinyl Chloride (LSPVC) | Orange | 100 % | Multi-Conductor | 75 ░C | 0 °C | Drain Wire Rip Cord | 4.45 mm | 0.175 in | 7 | 30 AWG | ||
Belden Inc. | Foil | 6 | Aluminum | Alarm Security Sound | 300 V | 0.015 in | 0.381 mm | 22 AWG | Copper Bare | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | UL Style CMP | Low Smoke Poly-Vinyl Chloride (LSPVC) | Natural | 100 % | Multi-Conductor | 75 ░C | 0 °C | Drain Wire Rip Cord | 4.45 mm | 0.175 in | 7 | 30 AWG | 500 ' | 152.4 m | ||
Belden Inc. | Foil | 6 | 3000 " | 76.2 m | Aluminum | Alarm Security Sound | 300 V | 0.015 in | 0.381 mm | 22 AWG | Copper Bare | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | UL Style CMP | Low Smoke Poly-Vinyl Chloride (LSPVC) | Natural | 100 % | Multi-Conductor | 75 ░C | 0 °C | Drain Wire Rip Cord | 4.45 mm | 0.175 in | 7 | 30 AWG | ||
Belden Inc. | Foil | 6 | 1000 ft | 304.8 m | Aluminum | Alarm Security Sound | 300 V | 0.015 in | 0.381 mm | 22 AWG | Copper Bare | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | UL Style CMP | Low Smoke Poly-Vinyl Chloride (LSPVC) | Violet | 100 % | Multi-Conductor | 75 ░C | 0 °C | Drain Wire Rip Cord | 4.45 mm | 0.175 in | 7 | 30 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Spool | 1000 | $ 0.36 | |
Description
General part information
6504FE Series
6 Conductor Multi-Conductor Cable Yellow 22 AWG Foil 1000.0' (304.8m)
