PQ2614BLA-6R8K

Active

Bourns Inc.

FIXED IND 6.8UH 30A 1.6 MOHM SMD

Search across all available documentation for this part.

Active

Bourns Inc.

FIXED IND 6.8UH 30A 1.6 MOHM SMD

Technical Specifications

Parameters and characteristics for this part

Part	Material - Core	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Inductance Frequency - Test	Type	Tolerance	Current Rating (Amps)	Ratings	DC Resistance (DCR) [Max]	Inductance	Shielding	Package / Case	Frequency - Self Resonant	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Current - Saturation (Isat)
Bourns Inc. PQ2614BLA-1R0K	Ferrite	0.63 in	16 mm	19.8 mm	1.098 in	0.78 in	27.9 mm	100 kHz	Drum Core Wirewound	10 %	30 A	AEC-Q200	1.2 mOhm	1 µH	Shielded	Nonstandard	61 MHz	-40 °C	155 °C	Surface Mount
Bourns Inc. PQ2614BLA-330K	Ferrite	0.63 in	16 mm	19.8 mm	1.098 in	0.78 in	27.9 mm	100 kHz	Drum Core Wirewound	10 %	30 A	AEC-Q200	1.6 mOhm	33 µH	Shielded	Nonstandard	7 MHz	-40 °C	155 °C	Surface Mount	2.6 A
Bourns Inc. PQ2614BLA-6R8K	Ferrite	0.63 in	16 mm	19.8 mm	1.098 in	0.78 in	27.9 mm	100 kHz	Drum Core Wirewound	10 %	30 A	AEC-Q200	1.6 mOhm	6.8 µH	Shielded	Nonstandard	25 MHz	-40 °C	155 °C	Surface Mount	26 A
Bourns Inc. PQ2614BLA-1R5K	Ferrite	0.63 in	16 mm	19.8 mm	1.098 in	0.78 in	27.9 mm	100 kHz	Drum Core Wirewound	10 %	30 A	AEC-Q200	1.6 mOhm	1.5 µH	Shielded	Nonstandard	60 MHz	-40 °C	155 °C	Surface Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

6.8 µH Shielded Drum Core, Wirewound Inductor 30 A 1.6mOhm Max Nonstandard
