MAX11300EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL KIT FOR MAX11300
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAX11300EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL KIT FOR MAX11300
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAX11300EVKIT# | MAX11300 Series |
|---|---|---|
| Contents | Cable(s), Board(s) | Board(s), Cable(s) |
| Data Interface | - | SPI |
| Function | ADC, DAC | ADC, DAC |
| Mounting Type | - | Surface Mount |
| Number of Channels | - | 20 |
| Operating Temperature | - | -40 °C |
| Operating Temperature | - | 105 ░C |
| Package / Case | - | 48-TQFP Exposed Pad, 40-WFQFN Exposed Pad |
| Primary Attributes | - | Pmod™-Compatible |
| Resolution (Bits) | - | 12 b |
| Secondary Attributes | SPI Interface(s) | Graphical User Interface (GUI), SPI Interface(s) |
| Supplied Contents | Cable(s), Board(s) | Board(s), Cable(s) |
| Supplier Device Package | - | 48-TQFP-EP (7x7), 40-TQFN |
| Type | Data Acquisition | Data Acquisition, DAC, ADC |
| Utilized IC / Part | MAX11300 | MAX11300 |
| Voltage - Supply | - | 1.62 V |
| Voltage - Supply | - | 5.5 V |
| Voltage Supply Source | - | Analog and Digital |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 124.78 | |
MAX11300 Series
EVAL KIT FOR MAX11300
| Part | Utilized IC / Part | Supplied Contents | Secondary Attributes | Contents | Function | Type | Supplier Device Package | Number of Channels | Voltage Supply Source | Mounting Type | Resolution (Bits) | Package / Case | Voltage - Supply [Min] | Voltage - Supply [Max] | Data Interface | Operating Temperature [Min] | Operating Temperature [Max] | Primary Attributes |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAX11300SYS1# | MAX11300 | Board(s) | Graphical User Interface (GUI) | Board(s) | ADC, DAC | Data Acquisition | ||||||||||||
Analog Devices Inc./Maxim Integrated MAX11300GCM+T | ADC, DAC | 48-TQFP-EP (7x7) | 20 | Analog and Digital | Surface Mount | 12 b | 48-TQFP Exposed Pad | 1.62 V | 5.5 V | SPI | -40 °C | 105 ░C | ||||||
Analog Devices Inc./Maxim Integrated MAX11300EVKIT# | MAX11300 | Board(s), Cable(s) | SPI Interface(s) | Board(s), Cable(s) | ADC, DAC | Data Acquisition | ||||||||||||
Analog Devices Inc./Maxim Integrated MAX11300GTL+ | ADC, DAC | 40-TQFN | 20 | Analog and Digital | Surface Mount | 12 b | 40-WFQFN Exposed Pad | 1.62 V | 5.5 V | SPI | -40 °C | 105 ░C | ||||||
Analog Devices Inc./Maxim Integrated MAX11300PMB1# | MAX11300 | Board(s) | Board(s) | ADC, DAC | Data Acquisition | Pmod™-Compatible | ||||||||||||
Analog Devices Inc./Maxim Integrated MAX11300GCM+ | ADC, DAC | 48-TQFP-EP (7x7) | 20 | Analog and Digital | Surface Mount | 12 b | 48-TQFP Exposed Pad | 1.62 V | 5.5 V | SPI | -40 °C | 105 ░C |
Description
General part information
MAX11300 Series
MAX11300 ADC, DAC Data Acquisition Evaluation Board
