31014 0082500

Active

Belden Inc.

HOOK-UP STRND 14AWG GRAY

Search across all available documentation for this part.

Active

Belden Inc.

HOOK-UP STRND 14AWG GRAY

Technical Specifications

Parameters and characteristics for this part

Specification	31014 0082500

Cable Type	Hook-Up
Conductor Material	Copper, Tinned
Conductor Strand [custom]	41
Conductor Strand [custom]	30 AWG
Jacket (Insulation) Diameter [diameter]	0.144 in
Jacket (Insulation) Diameter [diameter]	3.66 mm
Jacket (Insulation) Material	Polyethylene (XLPE), Irradiated
Jacket (Insulation) Thickness	0.81 mm
Jacket (Insulation) Thickness	0.032 in
Jacket Color	Gray
Length	2500 ft
Length	762 m
Voltage	600 V
Wire Gauge	13.5 AWG

Part	Wire Gauge	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Material	Jacket (Insulation) Material	Conductor Strand [custom]	Conductor Strand [custom]	Length	Length	Jacket Color	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Cable Type	Voltage
Belden Inc. 31014 0082500	13.5 AWG	0.81 mm	0.032 in	Copper Tinned	Polyethylene (XLPE) Irradiated	41	30 AWG	2500 ft	762 m	Gray	0.144 in	3.66 mm	Hook-Up	600 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	2500	$ 1.06

General part information

14 AWG Hook-Up Wire 41/30 Gray 600V 2500' (762.0m)
