4608M-901-103LF

Obsolete

Bourns Inc.

CAP ARRAY 10000PF 50V X7R 8SIP

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

4608M-901-103LF

Obsolete

Bourns Inc.

CAP ARRAY 10000PF 50V X7R 8SIP

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	4608M-901-103LF

Capacitance	10000 pF
Circuit Type	Bussed
Height - Seated (Max) [Max] [z]	5.08 mm
Height - Seated (Max) [Max] [z]	0.2 "
Mounting Type	Through Hole
Number of Capacitors	7
Package / Case	8-SIP
Size / Dimension [x]	0.803 "
Size / Dimension [x]	20.4 mm
Size / Dimension [y]	3.81 mm
Size / Dimension [y]	0.15 "
Temperature Coefficient	X7R
Tolerance	20 %
Voltage - Rated	50 VDC

4608M Series

Part	Resistor-Ratio-Drift	Mounting Type	Package / Case	Height - Seated (Max)	Height - Seated (Max) [Max]	Supplier Device Package	Operating Temperature [Min]	Operating Temperature [Max]	Power Per Element	Tolerance	Temperature Coefficient	Number of Resistors	Resistance (Ohms)	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Circuit Type	Number of Pins	Resistance (Ohms)	Capacitance	Voltage - Rated	Number of Capacitors	Temperature Coefficient	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
Bourns Inc. 4608M-101-473LF	50 ppm/°C	Through Hole	8-SIP	6.35 mm	0.25 in	8-SIP	-55 °C	125 °C	250 mW	2 %	100 ppm/°C	7	47k	0.798 "	20.27 mm	0.098 in	2.49 mm	Bussed	8
Bourns Inc. 4608M-102-393LF	50 ppm/°C	Through Hole	8-SIP	6.35 mm	0.25 in	8-SIP	-55 °C	125 °C		2 %	100 ppm/°C	4	39k	0.798 "	20.27 mm	0.098 in	2.49 mm	Isolated	8
Bourns Inc. 4608M-102-331LF	50 ppm/°C	Through Hole	8-SIP	6.35 mm	0.25 in	8-SIP	-55 °C	125 °C		2 %	100 ppm/°C	4		0.798 "	20.27 mm	0.098 in	2.49 mm	Isolated	8	330 Ohms
Bourns Inc. 4608M-102-470LF	50 ppm/°C	Through Hole	8-SIP	6.35 mm	0.25 in	8-SIP	-55 °C	125 °C		1 Ohm	250 ppm/°C	4		0.798 "	20.27 mm	0.098 in	2.49 mm	Isolated	8	47 Ohms
Bourns Inc. 4608M-102-271LF	50 ppm/°C	Through Hole	8-SIP	6.35 mm	0.25 in	8-SIP	-55 °C	125 °C		2 %	100 ppm/°C	4		0.798 "	20.27 mm	0.098 in	2.49 mm	Isolated	8	270 Ohms
Bourns Inc. 4608M-901-103LF		Through Hole	8-SIP							20 %				0.803 "	20.4 mm	0.15 "	3.81 mm	Bussed			10000 pF	50 VDC	7	X7R	5.08 mm	0.2 "
Bourns Inc. 4608M-101-154LF	50 ppm/°C	Through Hole	8-SIP	6.35 mm	0.25 in	8-SIP	-55 °C	125 °C	250 mW	2 %	100 ppm/°C	7	150k	0.798 "	20.27 mm	0.098 in	2.49 mm	Bussed	8
Bourns Inc. 4608M-102-561LF	50 ppm/°C	Through Hole	8-SIP	6.35 mm	0.25 in	8-SIP	-55 °C	125 °C		2 %	100 ppm/°C	4		0.798 "	20.27 mm	0.098 in	2.49 mm	Isolated	8	560 Ohms
Bourns Inc. 4608M-902-103LF		Through Hole	8-SIP							20 %				0.803 "	20.4 mm	0.15 "	3.81 mm	Isolated			10000 pF	50 VDC	4	X7R	5.08 mm	0.2 "
Bourns Inc. 4608M-102-391LF	50 ppm/°C	Through Hole	8-SIP	6.35 mm	0.25 in	8-SIP	-55 °C	125 °C		2 %	100 ppm/°C	4		0.798 "	20.27 mm	0.098 in	2.49 mm	Isolated	8	390 Ohms

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

4608M Series

10000pF Bussed Capacitor 7 Array 50 V X7R 8-SIP
