435626-1
ObsoleteTE Connectivity AMP Connectors
DIP SWITCHES / SIP SWITCHES LOW PROFILE DIP SW 4POS N AU
435626-1
ObsoleteTE Connectivity AMP Connectors
DIP SWITCHES / SIP SWITCHES LOW PROFILE DIP SW 4POS N AU
Description
General part information
435626 Series
Dip Switch SPST 4 Position Through Hole Rocker Actuator 25mA 24VDC
Technical Specifications
Parameters and characteristics for this part
| Specification | 435626-1 |
|---|---|
| Actuator Level | Flush, Recessed |
| Actuator Type | Rocker |
| Body Material | Glass Filled, Polyester, PET |
| Circuit | SPST |
| Contact Finish | Gold |
| Contact Material | Copper Alloy |
| Current Rating | 0.025 A |
| Electrical Life (Cycles) | 7000 |
| Height Above Board | 0.29 in |
| Length | 0.48 in |
| Mechanical Life (Cycles) | 7000 Cycles |
| Mounting Type | Through Hole |
| Number of Positions | 4 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -55 °C |
| Pitch | 0.1 in |
| Pitch Type | Full |
| Termination Style | PC Pin |
| Voltage Rating | 24 V |
| Washable | No |
