M2032TXG30-DC

Obsolete

NKK Switches

SWITCH ROCKER 3PDT 0.4VA 28V

Search across all available documentation for this part.

Obsolete

NKK Switches

SWITCH ROCKER 3PDT 0.4VA 28V

Technical Specifications

Parameters and characteristics for this part

Part	Electrical Life	Termination Style	Voltage Rating - AC	Actuator Type	Features	Operating Temperature [Min]	Operating Temperature [Max]	Voltage Rating - DC	Mounting Type	Circuit	Current Rating (Amps)	Actuator Marking	Switch Function	Approval Agency	Color - Actuator/Cap
NKK Switches M2032TXW13	25000 Steps	PC Pin	125 V	Actuator Arm Cap Required	Epoxy Sealed Terminals	-30 ░C	85 °C	30 V	Through Hole	3PDT	4 A 6 A	Varies by Cap	On-On	CSA UL
NKK Switches M2032TXW41/UC-DA	25000 Steps	PC Pin	125 V	Concave (Standard V)	Epoxy Sealed Terminals	-30 ░C	85 °C		Right Angle Through Hole Vertical	3PDT	6 A	No Marking	On-On	CSA UL	Black
NKK Switches M2032TXG30-DC	50000 Cycles	PC Pin	28 V	Concave (Standard V)	Epoxy Sealed Terminals	-30 ░C	85 °C	28 V	Through Hole Right Angle	3PDT	0.4 VA	No Marking	On-On	CSA UL	Red
NKK Switches M2032TXW13-DC	25000 Steps	PC Pin	125 V	Concave (Standard V)	Epoxy Sealed Terminals	-30 ░C	85 °C	30 V	Through Hole	3PDT	4 A 6 A	No Marking	On-On	CSA UL	Red
NKK Switches M2032TXW30-DA	25000 Steps	PC Pin	125 V	Concave (Standard V)	Epoxy Sealed Terminals	-30 ░C	85 °C	30 V	Through Hole Right Angle	3PDT	4 A 6 A	No Marking	On-On	CSA UL	Black

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Rocker Switch 3PDT 0.4VA (AC/DC) 28 V Through Hole, Right Angle
