DD03D4812A
ActiveDelta Electronics
DC DC CONVERTER +/-12V 3W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
DD03D4812A
ActiveDelta Electronics
DC DC CONVERTER +/-12V 3W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | DD03D4812A |
|---|---|
| Applications | Medical |
| Current - Output (Max) | 125 mA |
| Current - Output (Max) | 125 mA |
| Efficiency | 81 % |
| Features | UVLO, OCP, SCP |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 24-DIP Module |
| Package / Case | 12 Leads |
| Power (Watts) | 3 W |
| Size / Dimension [x] | 31.8 mm |
| Size / Dimension [x] | 1.25 " |
| Size / Dimension [y] | 0.8 in |
| Size / Dimension [y] | 20.3 mm |
| Size / Dimension [z] | 0.4 " |
| Size / Dimension [z] | 10.2 mm |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 75 V |
| Voltage - Input (Min) [Min] | 36 V |
| Voltage - Isolation | 1.5 kV |
| Voltage - Output 1 | 12 V |
| Voltage - Output 2 | -12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 100 | $ 12.17 | |
Description
General part information
DD03D Series
Isolated Module DC DC Converter 2 Output 12V -12V 125mA, 125mA 36V - 75V Input
