CI6303M2VR0-NH

Active

Cvilux USA

3 POS 1.20MM(.048) WIRE TO BOARD

Search across all available documentation for this part.

Active

Cvilux USA

3 POS 1.20MM(.048) WIRE TO BOARD

Technical Specifications

Parameters and characteristics for this part

Specification	CI6303M2VR0-NH

Connector Type	Header
Contact Finish - Post	Tin
Contact Material	Phosphor Bronze
Contact Shape	Rectangular
Contact Type	Male Pin
Fastening Type	Friction Lock
Features	Solder Retention
Insulation Color	Black
Insulation Height	0.057 in
Insulation Height	1.45 mm
Insulation Material	Polyamide (PA6T), Halogen Free, Nylon 6T
Material Flammability Rating	UL94 V-0
Mounting Type	Surface Mount
Number of Positions Loaded	All
Number of Rows	1
Shrouding	Shrouded - 3 Wall
Style	Board to Cable/Wire
Termination	Solder

Part	Shrouding	Contact Type	Termination	Contact Material	Number of Positions Loaded	Fastening Type	Style	Insulation Color	Features	Mounting Type	Contact Finish - Post	Contact Shape	Insulation Material	Number of Rows	Material Flammability Rating	Insulation Height	Insulation Height	Connector Type
Cvilux USA CI6303M2VR0-NH	Shrouded - 3 Wall	Male Pin	Solder	Phosphor Bronze	All	Friction Lock	Board to Cable/Wire	Black	Solder Retention	Surface Mount	Tin	Rectangular	Halogen Free Nylon 6T Polyamide (PA6T)	1	UL94 V-0	0.057 in	1.45 mm	Header

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Connector Header Surface Mount 3 position 0.059" (1.50mm)

Technical documentation and resources

No documents available
