MAX11213EVKIT+
ActiveAnalog Devices Inc./Maxim Integrated
KIT EVAL MAX11213
Deep-Dive with AI
Search across all available documentation for this part.
MAX11213EVKIT+
ActiveAnalog Devices Inc./Maxim Integrated
KIT EVAL MAX11213
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAX11213EVKIT+ | MAX11213 Series |
|---|---|---|
| Architecture | - | Sigma-Delta |
| Configuration | - | ADC |
| Data Interface | QSPI™, Serial, SPI™, MICROWIRE™ | QSPI™, Serial, SPI™, MICROWIRE™, SPI |
| Features | - | PGA |
| Input Range | ±VREF | ±VREF |
| Input Type | - | Differential |
| Mounting Type | - | Surface Mount |
| Number of A/D Converters | 1 | 1 |
| Number of Bits | 16 | 16 |
| Number of Inputs | - | 1 |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 0.154 in |
| Package / Case | - | 16-SSOP |
| Package / Case | - | 3.9 mm |
| Reference Type | - | External |
| Sampling Rate (Per Second) | - | 480 Per Second |
| Supplied Contents | Cable(s), Board(s) | Cable(s), Board(s) |
| Supplier Device Package | - | 16-QSOP |
| Utilized IC / Part | MAX11213 | MAX11213 |
| Voltage - Supply, Analog | - | 2.7 V |
| Voltage - Supply, Analog | - | 3.6 V |
| Voltage - Supply, Digital | - | 3.6 V |
| Voltage - Supply, Digital | - | 1.7 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
MAX11213 Series
KIT EVAL MAX11213
| Part | Supplied Contents | Input Range | Number of Bits | Data Interface | Utilized IC / Part | Number of A/D Converters | Package / Case | Package / Case | Package / Case | Features | Reference Type | Sampling Rate (Per Second) | Input Type | Configuration | Number of Inputs | Voltage - Supply, Digital [Max] | Voltage - Supply, Digital [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Architecture | Voltage - Supply, Analog [Min] | Voltage - Supply, Analog [Max] | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAX11213EVKIT+ | Board(s), Cable(s) | ±VREF | 16 | MICROWIRE™, QSPI™, Serial, SPI™ | MAX11213 | 1 | ||||||||||||||||||
Analog Devices Inc./Maxim Integrated MAX11213EEE+T | 16 | SPI | 1 | 0.154 in | 16-SSOP | 3.9 mm | PGA | External | 480 Per Second | Differential | ADC | 1 | 3.6 V | 1.7 V | 85 °C | -40 °C | Sigma-Delta | 2.7 V | 3.6 V | Surface Mount | 16-QSOP | |||
Analog Devices Inc./Maxim Integrated MAX11213EEE+ | 16 | SPI | 1 | 0.154 in | 16-SSOP | 3.9 mm | PGA | External | 480 Per Second | Differential | ADC | 1 | 3.6 V | 1.7 V | 85 °C | -40 °C | Sigma-Delta | 2.7 V | 3.6 V | Surface Mount | 16-QSOP |
Description
General part information
MAX11213 Series
MAX11213 - 16 Bit Samples per Second Analog to Digital Converter (ADC) Evaluation Board
