AM2GH-2403SZ

Active

DComponents

DC DC CONVERTER 3.3V 1.7W

Search across all available documentation for this part.

Active

DComponents

DC DC CONVERTER 3.3V 1.7W

Technical Specifications

Parameters and characteristics for this part

DC DC CONVERTER 3.3V 1.7W

Part	Number of Outputs	Package / Case	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Mounting Type	Current - Output (Max) [Max]	Voltage - Isolation	Voltage - Input (Min) [Min]	Type	Features	Voltage - Output 1	Operating Temperature [Max]	Operating Temperature [Min]	Applications	Approval Agency	Power (Watts)	Voltage - Input (Max) [Max]	Efficiency
DComponents AM2GH-2403SZ	1	8-SIP Module	9.2 mm	0.36 "	0.44 "	11.1 mm	21.9 mm	0.86 in	Through Hole	500 mA	1.6 kV	9 V	Isolated Module	Remote On/Off	3.3 V	85 °C	-40 °C	ITE (Commercial)	CE	2 W	36 V	71 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 1 Output 3.3V 500mA 9V - 36V Input
