CL-1-2005 Series

Part	Ratings	Voltage Color	Voltage (Green)	Voltage (Red)	Panel Cutout Dimension	Panel Cutout Shape	Wavelength - Peak (Red)	Wavelength - Peak Colors	Wavelength - Peak (Green)	Millicandela Rating Colors	Millicandela Rating (Red)	Millicandela Rating (Green)	Viewing Angle	Ingress Protection	Type	Lamp Color	Current (Green)	Current Colors	Current (Red)	Lens Style	Termination Length	Termination Style	Lens Color	Current
Visual Communications Company - VCC CL-1-2005-9912-I	DC If (Max) Vf (Typ)	Green Red	2.1 V 48 V	1.95 V 48 V	0.56 \	Round	645 nm	Green Red	574 nm	Green Red	750 mcd	130 mcd	50 °	IP67	LED	Green Red	20 mA	Green Red	20 mA	Domed Top Round	6 in	Wire Leads	Green Red
Visual Communications Company - VCC CL-1-2005-9907-I	DC If (Max) Vf (Typ)	Green Red	2.1 V 5 V	1.95 V 5 V	0.56 \	Round	645 nm	Green Red	574 nm	Green Red	750 mcd	130 mcd	50 °	IP67	LED	Green Red	20 mA	Green Red	20 mA	Domed Top Round	6 in	Wire Leads	Green Red
Visual Communications Company - VCC CL-1-2005-9910-I	DC	Green Red	24 V	24 V	0.551 "	Round	645 nm	Green Red	574 nm	Green Red	750 mcd	130 mcd	50 °	IP67	LED	Green Red				Domed Top Round	6 in	Wire Leads		20 mA
Visual Communications Company - VCC CL-1-2005-9908-I	DC	Green Red	12 V	12 V	0.551 "	Round	645 nm	Green Red	574 nm	Green Red	750 mcd	130 mcd	50 °	IP67	LED	Green Red				Domed Top Round	6 in	Wire Leads		20 mA
Visual Communications Company - VCC CL-1-2005-9914-I	DC If (Max) Vf (Typ)	Green Red	2.1 V 60 V	1.95 V 60 V	0.56 \	Round	645 nm	Green Red	574 nm	Green Red	750 mcd	130 mcd	50 °	IP67	LED	Green Red	20 mA	Green Red	20 mA	Domed Top Round	6 in	Wire Leads	Green Red

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources

No documents available
