PA41EC1100
ActiveE-Switch
SWITCH PUSH DPST-NO 16A 125V
Deep-Dive with AI
Search across all available documentation for this part.
PA41EC1100
ActiveE-Switch
SWITCH PUSH DPST-NO 16A 125V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | PA41EC1100 |
|---|---|
| Actuator Marking | No Marking |
| Actuator Type | Rectangular, Button |
| Circuit | DPST-NO |
| Color - Actuator/Cap | Black |
| Current Rating (Amps) | 16 A |
| Electrical Life | 10000 Cycles |
| Mounting Type | Panel Mount, Snap-In |
| Panel Cutout Dimensions [x] | 19 mm |
| Panel Cutout Dimensions [y] | 13 mm |
| Switch Function | Off-Mom |
| Termination Style | Quick Connect - 0.187" (4.7mm) |
| Type | Standard |
| Voltage Rating - AC | 125 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 2.22 | |
| 10 | $ 1.99 | |||
| 25 | $ 1.88 | |||
| 50 | $ 1.80 | |||
| 100 | $ 1.71 | |||
| 400 | $ 1.63 | |||
| 800 | $ 1.62 | |||
Description
General part information
PA41 Series
Pushbutton Switch DPST-NO Standard Panel Mount, Snap-In
Documents
Technical documentation and resources
No documents available
