32718 0104000

Active

Belden Inc.

HOOK-UP STRND 18AWG BLACK

Search across all available documentation for this part.

Active

Belden Inc.

HOOK-UP STRND 18AWG BLACK

Technical Specifications

Parameters and characteristics for this part

Specification	32718 0104000

Cable Type	Hook-Up
Conductor Material	Copper, Tinned
Conductor Strand [custom]	26 AWG
Conductor Strand [custom]	7
Jacket (Insulation) Diameter [diameter]	2.74 mm
Jacket (Insulation) Diameter [diameter]	0.108 "
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	0.8 mm
Jacket (Insulation) Thickness	0.031 in
Jacket Color	Black
Length [x]	1219.2 m
Length [x]	4000 ft
Ratings	UL Style 32718
Voltage	600 V
Wire Gauge	18 AWG

Part	Wire Gauge	Conductor Strand [custom]	Conductor Strand [custom]	Voltage	Ratings	Jacket (Insulation) Material	Jacket Color	Cable Type	Length [x]	Length [x]	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]
Belden Inc. 32718 0104000	18 AWG	26 AWG	7	600 V	UL Style 32718	Poly-Vinyl Chloride (PVC)	Black	Hook-Up	1219.2 m	4000 ft	0.8 mm	0.031 in	Copper Tinned	2.74 mm	0.108 "

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	4000	$ 0.47

General part information

18 AWG Hook-Up Wire 7/26 Black 600V 4000' (1219.2m)

Technical documentation and resources
