ICB18S30N08PO

Active

CARLO GAVAZZI

SENSOR PROX INDUCTIVE 8MM CYLIND

Search across all available documentation for this part.

Active

CARLO GAVAZZI

SENSOR PROX INDUCTIVE 8MM CYLIND

Technical Specifications

Parameters and characteristics for this part

Part	Sensor Type	Ingress Protection	Output Type	Package / Case	Voltage - Supply [Min]	Voltage - Supply [Max]	Termination Style	Material - Body	Indicator [custom]	Shielding	Sensing Distance	Sensing Distance	Operating Temperature [Max]	Operating Temperature [Min]
CARLO GAVAZZI ICB18S30N08NO	Inductive	IP67	4-Wire NPN-NO	Cylinder Threaded - M18	10 VDC	36 V	Cable Leads	Nickel-Plated Brass	LED	Unshielded	0.315 in	8 mm	70 °C	-25 °C
CARLO GAVAZZI ICB18S30F08PO	Inductive	IP67	4-Wire PNP-NO	Cylinder Threaded - M18	10 VDC	36 V	Cable Leads	Nickel-Plated Brass	LED	Unshielded	0.315 in	8 mm	70 °C	-25 °C
CARLO GAVAZZI ICB18S30N08PO	Inductive	IP67	4-Wire PNP-NO	Cylinder Threaded - M18	10 VDC	36 V	Cable Leads	Nickel-Plated Brass	LED	Unshielded	0.315 in	8 mm	70 °C	-25 °C
CARLO GAVAZZI ICB18S30N14NO	Inductive	IP67	NPN-NO 3-Wire	Cylinder Threaded - M18	10 VDC	36 V	Cable Leads	Nickel-Plated Brass	LED	Unshielded	0.551 in	14 mm	70 °C	-25 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

SENSOR PROX INDUCTIVE 8MM CYLIND
