977-025-020R121 - 977-025-020(-,R)121

977-025-020R121

Active
MH Connectors

D SUB BACKSHELL, ARMOR 977 SERIES, DB, 180°, ABS (ACRYLONITRILE BUTADIENE STYRENE) BODY

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDrawing EN3D Product Image EN+3
977-025-020R121 - 977-025-020(-,R)121

977-025-020R121

Active
MH Connectors

D SUB BACKSHELL, ARMOR 977 SERIES, DB, 180°, ABS (ACRYLONITRILE BUTADIENE STYRENE) BODY

Deep-Dive with AI

DocumentsDrawing EN3D Product Image EN+3

Technical Specifications

Parameters and characteristics for this part

Specification977-025-020R121
Accessory TypeTwo Piece Backshell
Cable Exit180 °
Cable TypeRound
ColorSilver
Compatible D-Sub SizeHD44pos, 25pos
Compatible Shell SizeB
FeaturesMating Screws 4-40
HardwareAssembly Hardware, Strain Relief
MaterialPlastic, Metallized
PlatingNickel over Copper
Primary MaterialPlastic
ShieldingShielded

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyBulk 1$ 2.23
10$ 1.71
25$ 1.53
50$ 1.42
100$ 1.31
250$ 1.19
500$ 1.11
1000$ 1.03
2500$ 1.00
NewarkEach 1$ 1.78
10$ 1.60
50$ 1.45
100$ 1.33
250$ 1.23

Description

General part information

977-025 Series

The 977 series straight top entry Backshell available in 5 industry sizes/positions (9, 15, 25, 37 and 50). It is available in metalized plastic and plastic. It is internal strain relief eliminates the need for grommets.
