SSI-LXMP059GD

Active

Lumex Opto/Components Inc.

LED 2X5MM GREEN PANEL MOUNT

Search across all available documentation for this part.

Active

Lumex Opto/Components Inc.

LED 2X5MM GREEN PANEL MOUNT

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

LED Panel Indicator Green Diffused 110° 2.2V 25mA

Technical documentation and resources

No documents available

Parameters and characteristics commom to parts in this series

LED 2X5MM GREEN PANEL MOUNT

Part	Voltage	Viewing Angle	Wavelength - Peak	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [y]	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [y]	Lens Transparency	Type	Panel Cutout Shape	Lamp Color	Lens Size [y]	Lens Size [x]	Current	Lens Style	Millicandela Rating	Lens Color
Lumex Opto/Components Inc. SSI-LXMP059GD	2.2 V	110 °	565 nm	0.26 "	0.18 "	6.6 mm	4.57 mm	Diffused	LED	Rectangle	Green	1.83 mm	4.2 mm	25 mA	Rectangle with Flat Top	10 mcd	Green
Lumex Opto/Components Inc. SSI-LXMP059ID	2 V	110 °	635 nm	0.26 "	0.18 "	6.6 mm	4.57 mm	Diffused	LED	Rectangle	Red	1.83 mm	4.2 mm	30 mA	Rectangle with Flat Top	10 mcd	Red
Lumex Opto/Components Inc. SSI-LXMP059USBD150	3.5 V	110 °		0.26 "	0.18 "	6.6 mm	4.57 mm	Diffused	LED	Rectangle	Blue	1.83 mm	4.19 mm		Rectangle with Flat Top	50 mcd	Blue
Lumex Opto/Components Inc. SSI-LXMP059GD-150	2.2 V	110 °	565 nm	0.26 "	0.18 "	6.6 mm	4.57 mm	Diffused	LED	Rectangle	Green	1.83 mm	4.2 mm	25 mA	Rectangle with Flat Top	10 mcd	Green
Lumex Opto/Components Inc. SSI-LXMP059SRD	1.7 V	110 °	660 nm	0.26 "	0.18 "	6.6 mm	4.57 mm	Diffused	LED	Rectangle	Red	1.83 mm	4.2 mm	30 mA	Rectangle with Flat Top	25 mcd	Red
Lumex Opto/Components Inc. SSI-LXMP059ID-150	2 V	110 °	635 nm	0.26 "	0.18 "	6.6 mm	4.57 mm	Diffused	LED	Rectangle	Red	1.83 mm	4.2 mm	30 mA	Rectangle with Flat Top	10 mcd	Red
