5300UG 010U1000

Active

Belden Inc.

CABLE 2COND 18AWG BLACK

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 2COND 18AWG BLACK

Technical Specifications

Parameters and characteristics for this part

Specification	5300UG 010U1000

Cable Type	Multi-Conductor
Conductor Insulation	Polypropylene (PP)
Conductor Material	Copper, Bare
Conductor Strand [custom]	26 AWG
Conductor Strand [custom]	7
Jacket (Insulation) Diameter [diameter]	3.76 mm
Jacket (Insulation) Diameter [diameter]	0.148 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	0.015 in
Jacket (Insulation) Thickness	0.381 mm
Jacket Color	Black
Length	1000 ft
Length	304.8 m
Number of Conductors	2
Usage	Sound, Security
Voltage	300 V
Wire Gauge	18 AWG

Part	Voltage	Usage	Jacket (Insulation) Material	Number of Conductors	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Insulation	Wire Gauge	Cable Type	Conductor Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Strand [custom]	Conductor Strand [custom]	Length	Length	Jacket Color	Length [x]	Length [x]
Belden Inc. 5300UG 008U1000	300 V	Security Sound	Poly-Vinyl Chloride (PVC)	2	0.015 in	0.381 mm	Polypropylene (PP)	18 AWG	Multi-Conductor	Copper Bare	3.76 mm	0.148 in	26 AWG	7	1000 ft	304.8 m	Gray
Belden Inc. 5300UG 008U500	300 V	Security Sound	Poly-Vinyl Chloride (PVC)	2	0.015 in	0.381 mm	Polypropylene (PP)	18 AWG	Multi-Conductor	Copper Bare	3.76 mm	0.148 in	26 AWG	7			Gray	500 '	152.4 m
Belden Inc. 5300UG 010U1000	300 V	Security Sound	Poly-Vinyl Chloride (PVC)	2	0.015 in	0.381 mm	Polypropylene (PP)	18 AWG	Multi-Conductor	Copper Bare	3.76 mm	0.148 in	26 AWG	7	1000 ft	304.8 m	Black

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 0.23

General part information

2 Conductor Multi-Conductor Cable Black 18 AWG 1000.0' (304.8m)
