FERD30H100SH

Obsolete

STMicroelectronics

DIODE FERD 100V 30A IPAK

Search across all available documentation for this part.

Obsolete

STMicroelectronics

DIODE FERD 100V 30A IPAK

Technical Specifications

Parameters and characteristics for this part

Specification	FERD30H100SH

Current - Average Rectified (Io)	30 A
Mounting Type	Through Hole
Operating Temperature - Junction [Max]	175 °C
Package / Case	IPAK, TO-251-3 Short Leads, TO-251AA
Speed	200 mA, 500 ns
Supplier Device Package	IPAK (TO-251)
Technology	FERD (Field Effect Rectifier Diode)
Voltage - DC Reverse (Vr) (Max) [Max]	100 V

45V, 30 A dual Field-Effect Rectifier Diode (FERD)

Part	Current - Average Rectified (Io)	Supplier Device Package	Package / Case	Mounting Type	Operating Temperature - Junction [Max]	Voltage - DC Reverse (Vr) (Max) [Max]	Technology	Speed	Diode Configuration	Voltage - Forward (Vf) (Max) @ If	Speed	Current - Reverse Leakage @ Vr	Current - Average Rectified (Io) (per Diode)
STMicroelectronics FERD30H100SH	30 A	IPAK (TO-251)	IPAK TO-251-3 Short Leads TO-251AA	Through Hole	175 °C	100 V	FERD (Field Effect Rectifier Diode)	200 mA 500 ns
STMicroelectronics FERD30M45CT		TO-220	TO-220-3	Through Hole	175 °C	45 V	FERD (Field Effect Rectifier Diode)		1 Pair Common Cathode	470 mV	No Recovery Time	600 µA	15 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

This dual center tap field effect rectifier provides stable leakage current over the full range of reverse voltage and low forward voltage drop.

Packaged in TO-220AB, I²PAK or D2PAK, this device is intended to be used in solar bypass junction boxes and in switch mode power supplies.
