LP38692SDX-ADJ/NOPB

Active

Texas Instruments

1-A, 10-V, ADJUSTABLE LOW-DROPOUT VOLTAGE REGULATOR WITH ENABLE

Find alt

Alpha

LP38692SDX-ADJ/NOPB

Active

Texas Instruments

1-A, 10-V, ADJUSTABLE LOW-DROPOUT VOLTAGE REGULATOR WITH ENABLE

Find alt

Alpha

Description Specifications Series Pricing CAD Documents

Description

General part information

LP38692 Series

The LP38690-ADJ and LP38692-ADJ low dropout CMOS linear regulators provide 2.5% precision reference voltage, extremely low dropout voltage (450 mV at 1-A load current, VOUT= 5 V) and excellent AC performance utilizing ultralow equivalent series resistance (ESR) ceramic output capacitors.

The low thermal resistance of the WSON and SOT-223 packages allow the full operating current to be used even in high ambient temperature environments.

The use of a PMOS power transistor means that no DC base drive current is required to bias it allowing ground pin current to remain below 100 µA regardless of load current, input voltage, or operating temperature. Dropout Voltage: 450 mV (typical) at 1 A (typical 5-V out) Ground Pin Current: 55 µA (typical) at full loadAdjust Pin Voltage: 2.5% (25°C) accuracy

Technical Specifications

Parameters and characteristics for this part

Specification	LP38692SDX-ADJ/NOPB

Current - Output	1 A
Current - Quiescent (Iq)	55 µA
Current - Supply (Max)	100 µA
Mounting Type	Surface Mount
Number of Regulators	1
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-40 °C
Output Configuration	Positive
Output Type	Adjustable
Package / Case	6-WDFN Exposed Pad
Package Length	3 mm
Package Name	6-WSON
Package Width	3 mm
Protection Features	Over Temperature
PSRR	55 dB
Voltage - Input (Max)	10 V
Voltage - Output (Max)	9 V
Voltage - Output (Min/Fixed)	1.25 V

LP38692 Series

Part	Package Name	Current - Output	Output Type	Mounting Type	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Input (Max)	Current - Quiescent (Iq)	Package / Case	Number of Regulators	Output Configuration	PSRR	Voltage Dropout (Max)	Protection Features	Current - Supply (Max)	Voltage - Output (Min/Fixed)	Supplied Contents	Board Type	Voltage - Input (Minimum)	Voltage - Input (Maximum)	Contents	Regulator Type	Channels per IC (Single)	Channels per IC (Type)	Channels per IC (Count)	Voltage - Output	Utilized IC / Part	Voltage - Output (Max)	Package Width	Package Length
Texas Instruments LP38692MP-3.3	SOT-223-5	1 A	Fixed	Surface Mount	125 °C	-40 °C	10 V	55 µA	TO-261-5 TO-261AB	1	Positive	55 dB	1 V	Over Temperature	100 µA	3.3 V
Texas Instruments LP38692EVAL		1 A															Board(s)	Fully Populated	2.7 V	10 V	Board	Positive Adjustable	1	Single	1	3.3 V	LP38692
Texas Instruments LP38692SD-ADJ	6-WSON	1 A	Adjustable	Surface Mount	125 °C	-40 °C	10 V	55 µA	6-WDFN Exposed Pad	1	Positive	55 dB		Over Temperature	100 µA	1.25 V												9 V	3 mm	3 mm
Texas Instruments LP38692SDX-1.8/NOPB	6-WSON	1 A	Fixed	Surface Mount	125 °C	-40 °C	10 V	55 µA	6-WDFN Exposed Pad	1	Positive	55 dB	1.6 V	Over Temperature	100 µA	1.8 V													3 mm	3 mm
Texas Instruments LP38692MP-5.0	SOT-223-5	1 A	Fixed	Surface Mount	125 °C	-40 °C	10 V	55 µA	TO-261-5 TO-261AB	1	Positive	55 dB	0.8 V	Over Temperature	100 µA	5 V
Texas Instruments LP38692MP-1.8	SOT-223-5	1 A	Fixed	Surface Mount	125 °C	-40 °C	10 V	55 µA	TO-261-5 TO-261AB	1	Positive	55 dB	1.6 V	Over Temperature	100 µA	1.8 V
Texas Instruments LP38692SDX-5.0/NOPB	6-WSON	1 A	Fixed	Surface Mount	125 °C	-40 °C	10 V	55 µA	6-WDFN Exposed Pad	1	Positive	55 dB	0.8 V	Over Temperature	100 µA	5 V													3 mm	3 mm
Texas Instruments LP38692SD-2.5/NOPB	6-WSON	1 A	Fixed	Surface Mount	125 °C	-40 °C	10 V	55 µA	6-WDFN Exposed Pad	1	Positive	55 dB	1.3 V	Over Temperature	100 µA	2.5 V													3 mm	3 mm
Texas Instruments LP38692MPX-5.0/NOPB	SOT-223	1 A	Fixed	Surface Mount	125 °C	-40 °C	10 V	55 µA	TO-261-5 TO-261AB	1	Positive	55 dB	0.8 V	Over Temperature	100 µA	5 V
Texas Instruments LP38692SD-3.3	6-WSON	1 A	Fixed	Surface Mount	125 °C	-40 °C	10 V	55 µA	6-WDFN Exposed Pad	1	Positive	55 dB	1 V	Over Temperature	100 µA	3.3 V													3 mm	3 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

LP3869x-ADJ 1-A Low Dropout CMOS Linear Regulator With Adjustable Output - Stable With Ceramic Output Capacitors datasheet (Rev. I)

AN-1424 LP38692-ADJ Evaluation Board (Rev. C)
