MS3456W20-27P

Active

Amphenol Aerospace Operations

CONN PLUG MALE 14POS GOLD CRIMP

Search across all available documentation for this part.

Active

Amphenol Aerospace Operations

CONN PLUG MALE 14POS GOLD CRIMP

Technical Specifications

Parameters and characteristics for this part

Specification	MS3456W20-27P

Applications	Aviation, Military, Automotive
Color	Olive Drab
Connector Type	Plug, Male Pins
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	1.27 µm
Contact Finish Thickness - Mating	50 µin
Contact Material	Copper Alloy
Features	Coupling Nut
Grade	Military
Ingress Protection	Fluid Resistant
Mounting Type	Free Hanging (In-Line)
Number of Positions	14
Operating Temperature [Max]	347 °F
Operating Temperature [Min]	-55 °C
Orientation	N
Primary Material	Metal
Qualification	MIL-DTL-5015
Shell Finish	Olive Drab Cadmium
Shell Material	Aluminum
Shell Size - Insert [Max]	27
Shell Size - Insert [Min]	20
Shielding	Unshielded
Termination	Crimp

Part	Contact Finish - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Termination	Ingress Protection	Primary Material	Shell Finish	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions	Orientation	Shielding	Shell Size - Insert [Max]	Shell Size - Insert [Min]	Grade	Applications	Qualification	Features	Shell Material	Mounting Type	Contact Material	Connector Type	Color
Amphenol Aerospace Operations MS3456W20-27P	Gold	1.27 µm	50 µin	Crimp	Fluid Resistant	Metal	Olive Drab Cadmium	-55 °C	347 °F	14	N	Unshielded	27	20	Military	Automotive Aviation Military	MIL-DTL-5015	Coupling Nut	Aluminum	Free Hanging (In-Line)	Copper Alloy	Male Pins Plug	Olive Drab
Amphenol Aerospace Operations MS3456W20-27S	Gold	1.27 µm	50 µin	Crimp	Fluid Resistant	Metal	Olive Drab Cadmium	-55 °C	347 °F	14	N	Unshielded	27	20	Military	Automotive Aviation Military	MIL-DTL-5015	Coupling Nut	Aluminum	Free Hanging (In-Line)	Copper Alloy	Female Sockets Plug	Olive Drab

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

14 (Power) Position Circular Connector Plug, Male Pins Crimp
