C4ATHBW4500A3FJ

Active

KEMET

CAP FILM 5UF 5% 600VDC RADIAL

Search across all available documentation for this part.

Active

KEMET

CAP FILM 5UF 5% 600VDC RADIAL

Technical Specifications

Parameters and characteristics for this part

Specification	C4ATHBW4500A3FJ

Applications	Switching, High Frequency, DC Filtering, DC Link
Capacitance	5 µF
Dielectric Material	Metallized, Polypropylene (PP)
ESR (Equivalent Series Resistance)	3.1 mOhms
Height - Seated (Max) [Max] [z]	1.575 in
Height - Seated (Max) [Max] [z]	40 mm
Lead Spacing	37.5 mm
Lead Spacing	1.476 in
Mounting Type	Through Hole
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Radial
Size / Dimension [x]	1.634 "
Size / Dimension [x]	41.5 mm
Size / Dimension [y]	20 mm
Size / Dimension [y]	0.787 in
Termination	PC Pins
Tolerance	5 %
Voltage Rating - AC	350 V
Voltage Rating - DC	600 V

Part	Tolerance	ESR (Equivalent Series Resistance)	Termination	Voltage Rating - DC	Voltage Rating - AC	Applications	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Package / Case	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Lead Spacing	Lead Spacing	Dielectric Material	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Capacitance	Size / Dimension [y]
KEMET C4ATHBW4500A3FJ	5 %	3.1 mOhms	PC Pins	600 V	350 V	DC Filtering DC Link High Frequency Switching	1.634 "	20 mm	41.5 mm	0.787 in	Radial	Through Hole	85 °C	-40 °C	37.5 mm	1.476 in	Metallized Polypropylene (PP)	1.575 in	40 mm	5 µF
KEMET C4ATHBW4900A3LJ	5 %	1.9 mOhms	PC Pins	600 V	350 V	DC Filtering DC Link High Frequency Switching	1.654 in	30 mm	42 mm	1.181 in	Radial - 4 Leads	Through Hole	85 °C	-40 °C	37.5 mm	1.476 in	Metallized Polypropylene (PP)	1.772 in	45 mm	9 µF
KEMET C4ATHBU4100A30J	5 %	7.7 mOhms	PC Pins	600 V	350 V	DC Filtering DC Link High Frequency Switching	1.26 in		32 mm	0.512 in	Radial	Through Hole	85 °C	-40 °C	27.5 mm	1.083 in	Metallized Polypropylene (PP)	0.787 "	20 mm	1 µF	13 mm
KEMET C4ATHBU4100A3BJ	5 %	7.7 mOhms	PC Pins	600 V	350 V	DC Filtering DC Link High Frequency Switching	1.26 in		32 mm	0.512 in	Radial	Through Hole	85 °C	-40 °C	27.5 mm	1.083 in	Metallized Polypropylene (PP)	0.866 in	22 mm	1 µF	13 mm
KEMET C4ATHBW4220A30J	5 %		PC Pins	600 V	350 V	DC Filtering DC Link High Frequency Switching	1.26 in	18 mm	32 mm	0.709 "	Radial	Through Hole	85 °C	-40 °C	27.5 mm	1.083 in	Metallized Polypropylene (PP)	1.299 in	33 mm	2.2 µF

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

5 µF Film Capacitor 350V 600V Polypropylene (PP), Metallized Radial
