3-1415358-1
ActiveTE Connectivity Potter & Brumfield Relays
RELAY GEN PURPOSE 4PDT 6A 48V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 3-1415358-1 |
|---|---|
| Approval Agency | cURus, VDE |
| Coil Current | 15.6 mA |
| Coil Insulation | Class F |
| Coil Resistance | 3.072 kOhms |
| Coil Type | Non Latching |
| Coil Voltage | 48 VDC |
| Contact Form | 4PDT (4 Form C) |
| Contact Material | Silver Nickel (AgNi) |
| Contact Rating (Current) | 6 A |
| Features | Test Button |
| Load - Max Switching [Max] | 2400 VA |
| Mounting Type | Through Hole |
| Must Operate Voltage | 36 VDC |
| Must Release Voltage | 4.8 VDC |
| Operate Time | 15 ms |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -40 °C |
| Relay Type | General Purpose |
| Release Time | 10 ms |
| Seal Rating | Sealed - Flux Protection |
| Switching Voltage [Max] | 400 VAC |
| Termination Style | PC Pin |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 16.05 | |
| 10 | $ 14.30 | |||
| 30 | $ 13.53 | |||
| 50 | $ 13.19 | |||
| 100 | $ 12.73 | |||
| 250 | $ 12.16 | |||
| 500 | $ 11.74 | |||
Description
General part information
1415358 Series
General Purpose Relay 4PDT (4 Form C) 48VDC Coil Through Hole
