JD54LS32BCA

Active

National Semiconductor

IC GATE OR 4CH 2-INP 14CERDIP

Search across all available documentation for this part.

Active

National Semiconductor

IC GATE OR 4CH 2-INP 14CERDIP

Technical Specifications

Parameters and characteristics for this part

Specification	JD54LS32BCA

Current - Output High, Low [custom]	4 mA
Current - Output High, Low [custom]	400 µA
Current - Quiescent (Max) [Max]	9.8 mA
Input Logic Level - Low	0.7 V
Logic Type	OR Gate
Max Propagation Delay @ V, Max CL	15 ns
Mounting Type	Through Hole
Number of Circuits	4
Number of Inputs	2
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Package / Case	14-CDIP
Supplier Device Package	14-CerDIP
Voltage - Supply [Max]	5.5 V
Voltage - Supply [Min]	4.5 V

Part	Logic Type	Voltage - Supply [Min]	Voltage - Supply [Max]	Number of Inputs	Input Logic Level - Low	Current - Output High, Low [custom]	Current - Output High, Low [custom]	Supplier Device Package	Package / Case	Max Propagation Delay @ V, Max CL	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Current - Quiescent (Max) [Max]	Number of Circuits
National Semiconductor JD54LS32BCA	OR Gate	4.5 V	5.5 V	2	0.7 V	4 mA	400 µA	14-CerDIP	14-CDIP	15 ns	-55 °C	125 °C	Through Hole	9.8 mA	4

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	105	$ 2.86

General part information

OR Gate IC 4 Channel 14-CERDIP
