D0840-42

Obsolete

Harwin Inc.

CONN IC DIP SOCKET 40POS GOLD

Search across all available documentation for this part.

Obsolete

Harwin Inc.

CONN IC DIP SOCKET 40POS GOLD

Technical Specifications

Parameters and characteristics for this part

Specification	D0840-42

Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	10 çin
Contact Finish Thickness - Mating	0.25 çm
Contact Finish Thickness - Post	196.9 µin
Contact Finish Thickness - Post	5 µm
Contact Material - Mating	Beryllium Copper
Contact Material - Post [custom]	Brass
Contact Resistance	10 mOhm
Current Rating (Amps)	1 A
Features	Open Frame
Housing Material	Glass Filled, Polyester, Polycyclohexylenedimethylene Terephthalate (PCT)
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions or Pins (Grid)	40
Number of Positions or Pins (Grid) [custom]	20
Number of Positions or Pins (Grid) [custom]	2
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Pitch - Mating	0.1 in
Pitch - Mating	2.54 mm
Pitch - Post	2.54 mm
Pitch - Post	0.1 in
Termination	Wire Wrap
Termination Post Length [x]	0.51 in
Termination Post Length [x]	12.95 mm
Type	DIP
Type	0.6 in
Type	15.24 mm

CONN IC DIP SOCKET 40POS GOLD

Part	Mounting Type	Contact Material - Post [custom]	Current Rating (Amps)	Contact Material - Mating	Contact Finish - Mating	Termination Post Length [x]	Termination Post Length [x]	Pitch - Mating	Pitch - Mating	Operating Temperature [Min]	Operating Temperature [Max]	Housing Material	Type	Type	Type	Features	Material Flammability Rating	Number of Positions or Pins (Grid)	Number of Positions or Pins (Grid) [custom]	Number of Positions or Pins (Grid) [custom]	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Resistance	Contact Finish - Post	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Pitch - Post	Pitch - Post	Termination
Harwin Inc. D0840-42	Through Hole	Brass	1 A	Beryllium Copper	Gold	0.51 in	12.95 mm	0.1 in	2.54 mm	-55 °C	125 °C	Glass Filled, Polycyclohexylenedimethylene Terephthalate (PCT), Polyester	DIP	0.6 in	15.24 mm	Open Frame	UL94 V-0	40	20	2	196.9 µin	5 µm	10 mOhm	Tin	10 çin	0.25 çm	2.54 mm	0.1 in	Wire Wrap

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

40 (2 x 20) Pos DIP, 0.6" (15.24mm) Row Spacing Socket Gold Through Hole
