45EG20AF

Active

Siemens

CONTACTOR, 45DP,30A,2P,OPEN,120V

Search across all available documentation for this part.

Active

Siemens

CONTACTOR, 45DP,30A,2P,OPEN,120V

Technical Specifications

Parameters and characteristics for this part

Part	Coil Voltage [Min]	Coil Voltage [Max]	Mounting Type	Contact Form	Operating Temperature	Contact Rating (Current)	Features	Termination Style	Switching Voltage	Coil Voltage
Siemens 45EG20AG	208 VAC	240 VAC	Chassis Mount	DPST-NO (2 Form A)	70 °C	30 A	Auxiliary Contacts	Screw Terminal	600 VAC
Siemens 45EG10AJA			Chassis Mount	SPST-NO (1 Form A)	70 °C	30 A	Auxiliary Contacts	Screw Terminal	600 VAC	24 VAC
Siemens 45EG20AH	440 VAC/DC	480 VAC/DC	Chassis Mount	DPST-NO (2 Form A)	70 °C	30 A	Auxiliary Contacts	Screw Terminal	600 VAC
Siemens 45EG10AFA	110 VAC/DC	120 VAC	Chassis Mount	SPST-NO (1 Form A)	70 °C	30 A	Auxiliary Contacts	Screw Terminal	600 VAC
Siemens 45EG10AGA	208 VAC	240 VAC	Chassis Mount	SPST-NO (1 Form A)	70 °C	30 A	Auxiliary Contacts	Screw Terminal	600 VAC
Siemens 45EG20AF	110 VAC/DC	120 VAC	Chassis Mount	DPST-NO (2 Form A)	70 °C	30 A	Auxiliary Contacts	Screw Terminal	600 VAC
Siemens 45EG20AL			Chassis Mount	DPST-NO (2 Form A)	70 °C	30 A	Auxiliary Contacts	Screw Terminal	600 VAC	277 VAC
