7829S-1-023LF
ActiveBourns Inc.
SWITCH ROTARY DIP SPDT 0.1A 16V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
7829S-1-023LF
ActiveBourns Inc.
SWITCH ROTARY DIP SPDT 0.1A 16V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 7829S-1-023LF |
|---|---|
| Actuator Level | Raised |
| Actuator Type | Rotary for Tool |
| Circuit | SPDT |
| Current Rating (Amps) | 100 mA |
| Height Above Board | 8.38 mm |
| Height Above Board | 0.33 in |
| Length | 0.26 in |
| Length | 6.6 mm |
| Mechanical Life | 2000 Cycles |
| Mounting Type | Through Hole, Right Angle |
| Number of Positions | 2 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Termination Style | PC Pin |
| Voltage Rating | 16 VAC/DC |
| Washable | True |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 400 | $ 1.55 | |
Description
General part information
7829S Series
Dip Switch SPDT 2 Position Through Hole, Right Angle Rotary for Tool Actuator 100mA 16VAC/DC
