3617-1500
Unknown3M (TC)
80400007847 3617-1500=PVCJACKET/RC/WSHIELD/1.50"WIDE/100
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
3617-1500
Unknown3M (TC)
80400007847 3617-1500=PVCJACKET/RC/WSHIELD/1.50"WIDE/100
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 3617-1500 |
|---|---|
| Color | Black, Silver |
| Diameter - Inside [diameter] | 1.5 in |
| Diameter - Inside [diameter] | 38.1 mm |
| Diameter - Outside [diameter] | 1.8 in |
| Diameter - Outside [diameter] | 45.72 mm |
| Features | Polyester Leader, Shielded |
| Heat Protection | Flame Retardant |
| Length | 100 ft, 10 ft, 5 ' |
| Length | 30.48 m, 3.05 m, 1.52 m, 15.24 m |
| Length [x] | 25 ft, 50 ft |
| Length [x] | 7.62 m |
| Material | Poly-Vinyl Chloride (PVC) |
| Type | Sleeving, Insulated |
| Type Attributes | Convoluted - Braided |
| Wall Thickness [custom] | 0.89 mm |
| Wall Thickness [custom] | 0.035 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
3617 Series
Black, Silver Poly-Vinyl Chloride (PVC) Convoluted - Braided Sleeving, Insulated 1.500" (38.10mm) 5.00' (1.52m)
