SF1102-6002

Active

Amphenol SV Microwave

SMA FEMALE TO PTNC FEMALE FLANGE MOUNT ADAPTER, 4 HOLE /INDIVIDUAL - BAG (PACK FILL QTY: 1)

Search across all available documentation for this part.

Active

Amphenol SV Microwave

SMA FEMALE TO PTNC FEMALE FLANGE MOUNT ADAPTER, 4 HOLE /INDIVIDUAL - BAG (PACK FILL QTY: 1)

Technical Specifications

Parameters and characteristics for this part

Specification	SF1102-6002

Adapter Series	SMA to PTNC
Adapter Type	Jack to Jack
Body Material	Stainless Steel
Center Contact Material	Beryllium Copper
Center Contact Plating	Gold
Center Gender	Female to Female
Conversion Type	Between Series
Convert From (Adapter End)	Female Socket, SMA Jack
Convert To (Adapter End)	PTNC Jack, Female Socket
Dielectric Material	Polytetrafluoroethylene (PTFE)
Frequency - Max [Max]	15 GHz
Impedance	50 Ohms
Mating Cycles	500
Mounting Feature	Flange
Style	Straight

Part	Mounting Feature	Style	Mating Cycles	Impedance	Adapter Series	Center Gender	Dielectric Material	Convert To (Adapter End)	Adapter Type	Convert From (Adapter End)	Center Contact Plating	Body Material	Frequency - Max [Max]	Conversion Type	Center Contact Material	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type
Amphenol SV Microwave SF1102-6002	Flange	Straight	500	50 Ohms	SMA to PTNC	Female to Female	Polytetrafluoroethylene (PTFE)	Female Socket PTNC Jack	Jack to Jack	Female Socket SMA Jack	Gold	Stainless Steel	15 GHz	Between Series	Beryllium Copper
Amphenol SV Microwave SF1102-6001		Straight	500	50 Ohms	SMA to PTNC	Female to Female	Polytetrafluoroethylene (PTFE)	Female Socket PTNC Jack	Jack to Jack	Female Socket SMA Jack	Gold	Stainless Steel	15 GHz	Between Series	Beryllium Copper	-65 ░C	165 °C	Free Hanging (In-Line)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Adapter Coaxial Connector SMA Jack, Female Socket To PTNC Jack, Female Socket 50 Ohms
