1445339-1
ActiveTE Connectivity Raychem Cable Protection
RCPT ASSY,4 POS,VERT,0.8MM MI
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
1445339-1
ActiveTE Connectivity Raychem Cable Protection
RCPT ASSY,4 POS,VERT,0.8MM MI
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 1445339-1 |
|---|---|
| Connector Type | Receptacle |
| Contact Finish - Mating | Gold |
| Contact Finish - Post | Gold |
| Contact Finish Thickness - Mating | 30 Áin |
| Contact Finish Thickness - Mating | 0.76 Ám |
| Contact Finish Thickness - Post | 0.13 Ám |
| Contact Finish Thickness - Post | 5.11 Áin |
| Contact Material | Phosphor Bronze |
| Contact Type | Female Blade Socket |
| Fastening Type | Friction Lock |
| Features | Solder Retention |
| Insulation Color | Beige |
| Insulation Height | 0.197 in |
| Insulation Height | 5 mm |
| Insulation Material | Liquid Crystal Polymer (LCP) |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Surface Mount |
| Number of Positions | 4 |
| Number of Positions Loaded | All |
| Number of Rows | 2 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -55 °C |
| Pitch - Mating | 0.031 in |
| Pitch - Mating | 0.8 mm |
| Style | Board to Board, Cable |
| Termination | Solder |
| Voltage Rating | 30 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 4.98 | |
| Tape & Reel (TR) | 1500 | $ 3.24 | ||
Description
General part information
1445339 Series
4 Position Receptacle Connector 0.031" (0.80mm) Surface Mount Gold
