TEL 8-2423WI

Active

Traco Power

DC DC CONVERTER +/-15V 8W

Search across all available documentation for this part.

Active

Traco Power

DC DC CONVERTER +/-15V 8W

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 2 Output 15V -15V 265mA, 265mA 9V - 36V Input

Technical documentation and resources

Parameters and characteristics commom to parts in this series

DC DC CONVERTER 15V 8W

Part	Efficiency	Number of Outputs	Type	Operating Temperature [Min]	Operating Temperature [Max]	Applications	Voltage - Output 1	Features	Package / Case	Package / Case	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Mounting Type	Voltage - Input (Max) [Max]	Voltage - Input (Min) [Min]	Power (Watts)	Voltage - Isolation	Current - Output (Max) [Max]	Voltage - Output 2	Current - Output (Max) [Min]	Current - Output (Max)	Current - Output (Max)
Traco Power TEL 8-4813	85 %	1	Isolated Module	-40 °C	80 C	ITE (Commercial)	15 V	SCP	16-DIP Module	6 Leads	14 mm	8.5 mm	0.33 in	0.95 in	24.1 mm	0.55 in	Through Hole	75 V	36 V	8 W	1.5 kV	535 mA
Traco Power TEL 8-1212	84 %	1	Isolated Module	-40 °C	80 C	ITE (Commercial)	12 V	SCP	16-DIP Module	6 Leads	14 mm	8.5 mm	0.33 in	0.95 in	24.1 mm	0.55 in	Through Hole	18 V	9 V	8 W	1.5 kV	665 mA
Traco Power TEL 8-4815WI	86 %	1	Isolated Module	-40 °C	80 ¯C	ITE (Commercial)	24 V	SCP	16-DIP Module	6 Leads	14 mm	8.5 mm	0.33 in	0.95 in	24.1 mm	0.55 in	Through Hole	75 V	18 V	8 W	1.5 kV	335 mA
Traco Power TEL 8-4822	86 %	2	Isolated Module	-40 °C	80 C	ITE (Commercial)	12 V	SCP	16-DIP Module	6 Leads	14 mm	8.5 mm	0.33 in	0.95 in	24.1 mm	0.55 in	Through Hole	75 V	36 V	8 W	1.5 kV	335 mA	-12 V	335 mA
Traco Power TEL 8-2423WI	86 %	2	Isolated Module	-40 °C	80 ¯C	ITE (Commercial)	15 V	SCP	16-DIP Module	6 Leads	14 mm	8.5 mm	0.33 in	0.95 in	24.1 mm	0.55 in	Through Hole	36 V	9 V	8 W	1.5 kV		-15 V		265 mA	265 mA
