3-216791-4

Active

TE Connectivity Raychem Cable Protection

CONN DIP HDR IDC 34POS PCB

Deep-Dive with AI

Search across all available documentation for this part.

3-216791-4

Active

TE Connectivity Raychem Cable Protection

CONN DIP HDR IDC 34POS PCB

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	3-216791-4

Board-Side Pitch	0.1 in
Board-Side Pitch	2.54 mm
Cable Pitch	1.27 mm
Cable Pitch	0.05 in
Cable Termination	IDC
Color	Gray
Connector Type	Ribbon Cable, DIP Header
Contact Finish	Tin
Contact Finish Thickness	3 µm
Contact Finish Thickness	118.1 µin
Features	Feed Through
Mounting Type	Through Hole, Press-Fit
Number of Positions	34
Number of Positions Loaded	All
Number of Rows	2
Row Spacing	2.54 mm
Row Spacing [x]	0.1 in

AMP-LATCH DIL-PLUG Series

Part	Contact Finish Thickness	Contact Finish Thickness	Number of Positions	Cable Pitch	Cable Pitch	Connector Type	Mounting Type	Board-Side Pitch	Board-Side Pitch	Contact Finish	Color	Number of Rows	Cable Termination	Number of Positions Loaded	Row Spacing [x]	Row Spacing	Features
TE Connectivity Raychem Cable Protection 4-216792-0	3 µm	118.1 µin	40	1.27 mm	0.05 in	DIP Header Ribbon Cable	Through Hole Press-Fit	0.1 in	2.54 mm	Tin	Gray	2	IDC	All	0.1 in	2.54 mm	Feed Through
TE Connectivity Raychem Cable Protection 3-216791-4	3 µm	118.1 µin	34	1.27 mm	0.05 in	DIP Header Ribbon Cable	Through Hole Press-Fit	0.1 in	2.54 mm	Tin	Gray	2	IDC	All	0.1 in	2.54 mm	Feed Through
TE Connectivity Raychem Cable Protection 2-216792-0	3 µm	118.1 µin	20	1.27 mm	0.05 in	DIP Header Ribbon Cable	Through Hole Press-Fit	0.1 in	2.54 mm	Tin	Gray	2	IDC	All	0.1 in	2.54 mm	Feed Through
TE Connectivity Raychem Cable Protection 5-216791-0	3 µm	118.1 µin	50	1.27 mm	0.05 in	DIP Header Ribbon Cable	Through Hole Press-Fit	0.1 in	2.54 mm	Tin	Gray	2	IDC	All	0.1 in	2.54 mm	Feed Through
TE Connectivity Raychem Cable Protection 2-216791-0	3 µm	118.1 µin	20	1.27 mm	0.05 in	DIP Header Ribbon Cable	Through Hole Press-Fit	0.1 in	2.54 mm	Tin	Gray	2	IDC	All	0.1 in	2.54 mm	Feed Through
TE Connectivity Raychem Cable Protection 1-216119-0	3 µm	118.1 µin	10	1.27 mm	0.05 in	DIP Header Ribbon Cable	Through Hole	0.1 in	2.54 mm	Tin	Gray	2	IDC	All	0.1 in	2.54 mm	Feed Through
TE Connectivity Raychem Cable Protection 1-216792-0	3 µm	118.1 µin	10	1.27 mm	0.05 in	DIP Header Ribbon Cable	Through Hole Press-Fit	0.1 in	2.54 mm	Tin	Gray	2	IDC	All	0.1 in	2.54 mm	Feed Through
TE Connectivity Raychem Cable Protection 216791-6	3 µm	118.1 µin	6	1.27 mm	0.05 in	DIP Header Ribbon Cable	Through Hole Press-Fit	0.1 in	2.54 mm	Tin	Gray	2	IDC	All	0.1 in	2.54 mm	Feed Through
TE Connectivity Raychem Cable Protection 3-216792-4	3 µm	118.1 µin	34	1.27 mm	0.05 in	DIP Header Ribbon Cable	Through Hole Press-Fit	0.1 in	2.54 mm	Tin	Gray	2	IDC	All	0.1 in	2.54 mm	Feed Through
TE Connectivity Raychem Cable Protection 2-216792-6	3 µm	118.1 µin	26	1.27 mm	0.05 in	DIP Header Ribbon Cable	Through Hole Press-Fit	0.1 in	2.54 mm	Tin	Gray	2	IDC	All	0.1 in	2.54 mm	Feed Through

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 3.30
		50	$ 2.90
		100	$ 2.61
		1000	$ 2.15
		5000	$ 1.86

Description

General part information

AMP-LATCH DIL-PLUG Series

34 Position Ribbon Cable, DIP Header Connector Gray IDC Through Hole, Press-Fit
