6EP43477RC000AX0 - 6EP43477RC000AX0

6EP43477RC000AX0

Active
Siemens

SITOP RED1200/REDM./DC24/48V/2X2

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheetPower Supplies Decision Guide+2
6EP43477RC000AX0 - 6EP43477RC000AX0

6EP43477RC000AX0

Active
Siemens

SITOP RED1200/REDM./DC24/48V/2X2

Deep-Dive with AI

DocumentsDatasheetPower Supplies Decision Guide+2

Technical Specifications

Parameters and characteristics for this part

Specification6EP43477RC000AX0
ApplicationsIndustrial, ITE (Commercial)
Approval AgencyEAC, CSA, CE, cULus
Current - Output (Max) [Max]40 A
DC Voltage - Input (Max) [Max]58 V
DC Voltage - Input (Min) [Min]10 V
Efficiency97.5 %
FeaturesAdjustable Output
Input TypeDC
Number of Outputs1
Operating Temperature [Max]70 °C
Operating Temperature [Min]-30 ░C
Size / Dimension [x]4.92 in
Size / Dimension [x]125 mm
Size / Dimension [y]45 mm
Size / Dimension [y]1.77 "
Size / Dimension [z]5.31 "
Size / Dimension [z]135 mm
Standard Number62368-1, UL 508
Voltage - Output 124 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyBulk 1$ 261.78

Description

General part information

6EP43477 Series

SITOP RED1200/REDM./DC24/48V/2X2
