MAXREFDES113C#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL BOARD FOR MAX17596
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAXREFDES113C#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL BOARD FOR MAX17596
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAXREFDES113C# | MAXREFDES113 Series |
|---|---|---|
| Board Type | Fully Populated | Fully Populated |
| Current - Output | 1.6 A | 1.6 A |
| Frequency - Switching | 200 kHz | 200 kHz |
| Main Purpose | DC/DC Converter | DC/DC Converter |
| Outputs and Type | Isolated | Isolated |
| Outputs and Type | 1 | 1 |
| Power - Output | 20 W | 20 W |
| Regulator Topology | Flyback | Flyback |
| Supplied Contents | Board(s) | Board(s) |
| Utilized IC / Part | MAX17596 | MAX17596 |
| Voltage - Input [Max] | 36 V | 36 V |
| Voltage - Input [Min] | 17 V | 17 V |
| Voltage - Output | 12 V | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 25.61 | |
| 10 | $ 25.55 | |||
MAXREFDES113 Series
EVAL BOARD FOR MAX17596
| Part | Power - Output | Board Type | Regulator Topology | Voltage - Input [Min] | Voltage - Input [Max] | Voltage - Output | Utilized IC / Part | Main Purpose | Supplied Contents | Outputs and Type | Outputs and Type | Current - Output | Frequency - Switching |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAXREFDES113B# | 20 W | Fully Populated | Flyback | 17 V | 36 V | 12 V | MAX17596 | DC/DC Converter | Board(s) | Isolated | 1 | 1.6 A | 200 kHz |
Analog Devices Inc./Maxim Integrated MAXREFDES113D# | 20 W | Fully Populated | Flyback | 17 V | 36 V | 12 V | MAX17596 | DC/DC Converter | Board(s) | Isolated | 1 | 1.6 A | 200 kHz |
Analog Devices Inc./Maxim Integrated MAXREFDES113A# | 20 W | Fully Populated | Flyback | 17 V | 36 V | 12 V | MAX17596 | DC/DC Converter | Board(s) | Isolated | 1 | 1.6 A | 200 kHz |
Analog Devices Inc./Maxim Integrated MAXREFDES113C# | 20 W | Fully Populated | Flyback | 17 V | 36 V | 12 V | MAX17596 | DC/DC Converter | Board(s) | Isolated | 1 | 1.6 A | 200 kHz |
Description
General part information
MAXREFDES113 Series
MAX17596 - DC/DC Converter 1, Isolated Outputs Evaluation Board
Documents
Technical documentation and resources
