009175003702906
ActiveKYOCERA AVX
FYE INDUSTRIAL - FALCON / TAPE/REEL ROHS COMPLIANT: YES
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 009175003702906 | 009175 Series |
|---|---|---|
| Board-Side Pitch | 2.5 mm | 2.5 mm |
| Board-Side Pitch | 0.098 in | 0.098 in |
| Cable Pitch | 2.5 mm | 2.5 mm |
| Cable Pitch | 0.098 in | 0.098 in |
| Cable Termination | IDC | IDC |
| Color | White | White |
| Connector Type | Individual Wires | Individual Wires |
| Contact Finish | Tin | Tin |
| Features | Feed Through | Closed End, Feed Through |
| Mounting Type | Surface Mount, Right Angle | Surface Mount, Right Angle, Surface Mount |
| Number of Positions | - | 2 |
| Number of Positions Loaded | All | All |
| Number of Rows | 1 | 1 |
| Wire Gauge | 26 AWG | 26 - 28 AWG |
| Wire Gauge | - | Stranded or Solid |
009175 Series
CONN WIRE IDC 3POS 26AWG SMD RA
| Part | Number of Rows | Connector Type | Features | Wire Gauge | Number of Positions Loaded | Mounting Type | Color | Board-Side Pitch | Board-Side Pitch | Contact Finish | Cable Termination | Cable Pitch | Cable Pitch | Number of Positions | Wire Gauge |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
KYOCERA AVX 009175003702996 | 1 | Individual Wires | Closed End | 26 AWG | All | Surface Mount, Right Angle | White | 2.5 mm | 0.098 in | Tin | IDC | 2.5 mm | 0.098 in | ||
KYOCERA AVX 009175002702996 | 1 | Individual Wires | Closed End | 26 AWG | All | Surface Mount, Right Angle | White | 2.5 mm | 0.098 in | Tin | IDC | 2.5 mm | 0.098 in | 2 | |
KYOCERA AVX 009175002701106 | 1 | Individual Wires | Feed Through | 28 AWG | All | Surface Mount | White | 2.5 mm | 0.098 in | Tin | IDC | 2.5 mm | 0.098 in | 2 | Stranded or Solid |
KYOCERA AVX 009175002702906 | 1 | Individual Wires | Feed Through | 26 AWG | All | Surface Mount, Right Angle | White | 2.5 mm | 0.098 in | Tin | IDC | 2.5 mm | 0.098 in | 2 | |
KYOCERA AVX 009175003702906 | 1 | Individual Wires | Feed Through | 26 AWG | All | Surface Mount, Right Angle | White | 2.5 mm | 0.098 in | Tin | IDC | 2.5 mm | 0.098 in |
