Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Spool | 1000 | $ 1.00 | |
General part information
8 (4 Pair) Conductor Multi-Pair, Cat6a Cable Gray 23 AWG Foil 1000.0' (304.8m)
Technical documentation and resources
Parameters and characteristics commom to parts in this series
| Specification | 10GX62F 0081000 | 10GX62F Series |
|---|---|---|
| Cable Type | Multi-Pair, Cat6a | Multi-Pair, Cat6a |
| Conductor Insulation | Polyolefin (PO) | Polyolefin (PO) |
| Conductor Material | Copper, Bare | Copper, Bare |
| Conductor Strand | Solid | Solid |
| Features | Rip Cord, Drain Wire | Rip Cord, Drain Wire |
| Jacket (Insulation) Diameter [diameter] | 7.62 mm | 7.62 mm |
| Jacket (Insulation) Diameter [diameter] | 0.3 in | 0.3 in |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC), Riser | Poly-Vinyl Chloride (PVC), Riser |
| Jacket Color | Gray | Gray, Yellow, Black, Red, Blue |
| Length | 1000 ft | 1000 ft |
| Length | 304.8 m | 304.8 m |
| Number of Conductors | 8 | 8 |
| Ratings | UL Style CMR | UL Style CMR |
| Shield Coverage | 100 % | 100 % |
| Shield Material | Polyester, Aluminum | Polyester, Aluminum |
| Shield Type | Foil | Foil |
| Usage | Network | Network |
| Voltage | 300 V | 300 V |
| Wire Gauge | 23 AWG | 23 AWG |
CAT6A 4PRB F/UTP CMR REEL
| Part | Wire Gauge | Jacket Color | Ratings | Usage | Number of Conductors | Cable Type | Conductor Strand | Features | Shield Material | Shield Coverage | Length | Length | Conductor Insulation | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Material | Shield Type | Voltage | Conductor Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Belden Inc. 10GX62F 0081000 | 23 AWG | Gray | UL Style CMR | Network | 8 | Multi-Pair, Cat6a | Solid | Drain Wire, Rip Cord | Aluminum, Polyester | 100 % | 1000 ft | 304.8 m | Polyolefin (PO) | 7.62 mm | 0.3 in | Poly-Vinyl Chloride (PVC), Riser | Foil | 300 V | Copper, Bare |
Belden Inc. 10GX62F 0041000 | 23 AWG | Yellow | UL Style CMR | Network | 8 | Multi-Pair, Cat6a | Solid | Drain Wire, Rip Cord | Aluminum, Polyester | 100 % | 1000 ft | 304.8 m | Polyolefin (PO) | 7.62 mm | 0.3 in | Poly-Vinyl Chloride (PVC), Riser | Foil | 300 V | Copper, Bare |
Belden Inc. 10GX62F 0101000 | 23 AWG | Black | UL Style CMR | Network | 8 | Multi-Pair, Cat6a | Solid | Drain Wire, Rip Cord | Aluminum, Polyester | 100 % | 1000 ft | 304.8 m | Polyolefin (PO) | 7.62 mm | 0.3 in | Poly-Vinyl Chloride (PVC), Riser | Foil | 300 V | Copper, Bare |
Belden Inc. 10GX62F 0021000 | 23 AWG | Red | UL Style CMR | Network | 8 | Multi-Pair, Cat6a | Solid | Drain Wire, Rip Cord | Aluminum, Polyester | 100 % | 1000 ft | 304.8 m | Polyolefin (PO) | 7.62 mm | 0.3 in | Poly-Vinyl Chloride (PVC), Riser | Foil | 300 V | Copper, Bare |
Belden Inc. 10GX62F 0061000 | 23 AWG | Blue | UL Style CMR | Network | 8 | Multi-Pair, Cat6a | Solid | Drain Wire, Rip Cord | Aluminum, Polyester | 100 % | 1000 ft | 304.8 m | Polyolefin (PO) | 7.62 mm | 0.3 in | Poly-Vinyl Chloride (PVC), Riser | Foil | 300 V | Copper, Bare |
Belden Inc. 10GX62F 0091000 | 23 AWG | UL Style CMR | Network | 8 | Multi-Pair, Cat6a | Solid | Drain Wire, Rip Cord | Aluminum, Polyester | 100 % | 1000 ft | 304.8 m | Polyolefin (PO) | 7.62 mm | 0.3 in | Poly-Vinyl Chloride (PVC), Riser | Foil | 300 V | Copper, Bare |
