Specification	15050VA-48P-EA-00

Air Flow	283.1 CFM
Approval Agency	VDE, UL
Bearing Type	Ball
Current Rating	0.52 A
Fan Type	Tubeaxial
Lifetime	100000 Hrs
Material - Blade	Plastic
Material - Frame	Aluminum
Noise	63 dB
Operating Temperature (Max)	158 °F
Operating Temperature (Min)	14 °F
Power (Watts)	25 W
RPM	3750 RPM
Size / Dimension Height	150 mm
Size / Dimension Length	172 mm
Size / Dimension Shape	Rectangular/Rounded
Static Pressure	0.846 in H2O
Termination	2 Wire Leads
Termination Leads Count	2 leads
Termination Type	Wire Leads
Voltage - Rated	48 VDC
Voltage Range (Max)	56 VDC
Voltage Range (Min)	36 VDC
Weight	1.8 lbs
Width	2 in

15050VA Series

DC Fans DC Axial Fan, 150x50mm Round, 24VDC, 225.9CFM, Flange Mount, Ball, Lead Wires

Part	Approval Agency	Fan Type	Weight	Voltage - Rated	RPM	Bearing Type	Operating Temperature (Max)	Operating Temperature (Min)	Static Pressure	Termination Leads Count	Termination Type	Termination	Air Flow	Size / Dimension Height	Size / Dimension Shape	Size / Dimension Length	Noise	Power (Watts)	Width	Current Rating	Voltage Range (Max)	Voltage Range (Min)	Lifetime	Material - Blade	Material - Frame	Ingress Protection Description	Ingress Protection IP Rating	Features
NMB TECHNOLOGIES 15050VA-48P-EA-00	UL VDE	Tubeaxial	1.8 lbs	48 VDC	3750 RPM	Ball	158 °F	14 °F	0.846 in H2O	2 leads	Wire Leads	2 Wire Leads	283.1 CFM	150 mm	Rectangular/Rounded	172 mm	63 dB	25 W	2 in	0.52 A	56 VDC	36 VDC	100000 Hrs	Plastic	Aluminum
NMB TECHNOLOGIES 15050VA-48M-EA-YY		Tubeaxial	1.8 lbs	48 VDC	2550 RPM	Ball	158 °F	14 °F	0.428 in H2O	2 leads	Wire Leads	2 Wire Leads	194.5 CFM	150 mm	Rectangular/Rounded	172 mm	51 dB	13.4 W	2 in	0.28 A	56 VDC	36 VDC	100000 Hrs	Plastic	Aluminum
NMB TECHNOLOGIES 15050VA-24Q-GA-00		Tubeaxial		24 VAC	4000 RPM	Ball	158 °F	14 °F	1.072 in H2O	2 leads	Wire Leads	2 Wire Leads	304 CFM	150 mm	Rectangular/Rounded	172.7 mm	64 dB	31.2 W	2 in							Dust Tight High Temp Water Jets Waterproof	IP69K	Auto Restart
NMB TECHNOLOGIES 15050VA-48N-EU-01	CE cULus VDE	Tubeaxial		48 VDC	3500 RPM	Ball	158 °F	14 °F	0.74 in H2O	4 leads	Wire Leads	4 Wire Leads	261.3 CFM	150 mm	Rectangular/Rounded	172 mm	60 dB	21.6 W	2 in	0.45 A	52.8 VDC	38 VDC	100000 Hrs	Plastic	Aluminum			Auto Restart PWM Control Speed Sensor (Tach)
NMB TECHNOLOGIES 15050VA-24Q-GA-00		Tubeaxial		24 VAC	4000 RPM	Ball	158 °F	14 °F	1.072 in H2O	2 leads	Wire Leads	2 Wire Leads	304 CFM	150 mm	Rectangular/Rounded	172.7 mm	64 dB	31.2 W	2 in	1.3 A	26.4 VDC	18 VDC	100000 Hrs	Plastic	Aluminum	Dust Tight High Temp Water Jets Waterproof	IP69K	Auto Restart
NMB TECHNOLOGIES 15050VA-48R-GA-00		Tubeaxial	1.9 lbs	48 VDC	4600 RPM	Ball	158 °F	14 °F	1.25 in H2O	2 leads	Wire Leads	2 Wire Leads	346.1 CFM	150 mm	Rectangular/Rounded	172.7 mm	68 dB	43.2 W	2 in	900 mA	52.8 VDC	38 VDC		Plastic	Aluminum	Dust Tight High Temp Water Jets Waterproof	IP69K
NMB TECHNOLOGIES 15050VA-24N-EA-00		Tubeaxial		24 VAC	3500 RPM	Ball	158 °F	14 °F	0.735 in H2O	2 leads	Wire Leads	2 Wire Leads	261.3 CFM	150 mm	Rectangular/Rounded	172.7 mm	60 dB	21.6 W	2 in	900 mA	26.4 VDC	18 VDC	100000 Hrs	Plastic	Aluminum			Auto Restart
