Specification	DCM24AP480T320A50

Applications	ITE (Commercial)
Current - Output (Max)	6.67 A
Efficiency	92.5 %
Features	OCP, Remote On/Off, OTP, UVLO, SCP, OVP
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-40 °C
Package / Case	9-DIP Module
Power (Watts)	320 W
Size / Dimension Height	0.29 in
Size / Dimension Length	1.52 in
Size / Dimension Width	0.9 in
Type	Isolated Module
Voltage - Input (Max)	36 V
Voltage - Input (Min)	18 V
Voltage - Isolation	2.25 kV
Voltage - Output 1	48 V

DCM24 Series

Part	Current - Output (Max)	Package / Case	Voltage - Isolation	Voltage - Input (Max)	Efficiency	Mounting Type	Features	Size / Dimension Width	Size / Dimension Length	Size / Dimension Height	Voltage - Output 1	Type	Number of Outputs	Voltage - Input (Min)	Power (Watts)	Operating Temperature (Max)	Operating Temperature (Min)	Applications
Vicor Corporation DCM24AP120M320A50	26.67 A	9-DIP Module	2.25 kV	36 V	93.1 %	Through Hole	OCP OTP OVP SCP UVLO	0.9 in	1.52 in	0.29 in	12 V	Isolated Module	1	18 V	320 W	125 °C	-55 °C	ITE (Commercial)
Vicor Corporation DCM24AP480T320A50	6.67 A	9-DIP Module	2.25 kV	36 V	92.5 %	Through Hole	OCP OTP OVP Remote On/Off SCP UVLO	0.9 in	1.52 in	0.29 in	48 V	Isolated Module	1	18 V	320 W	125 °C	-40 °C	ITE (Commercial)
Vicor Corporation DCM24AP050T180A50	36 A	9-DIP Module	2.25 kV	36 V	91.9 %	Through Hole	OCP OTP OVP Remote On/Off SCP UVLO	0.9 in	1.52 in	0.29 in	5 V	Isolated Module	1	18 V	180 W	125 °C	-40 °C	ITE (Commercial)
Vicor Corporation DCM24AP150T320A50	21.4 A	9-DIP Module	2.25 kV	36 V	92.9 %	Through Hole	OCP OTP OVP Remote On/Off SCP UVLO	0.9 in	1.52 in	0.29 in	15 V	Isolated Module	1	18 V	320 W	125 °C	-40 °C	ITE (Commercial)
