AM3G-1224SH30-NZ
Activeaimtec
DC DC CONVERTER 24V 3W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AM3G-1224SH30-NZ
Activeaimtec
DC DC CONVERTER 24V 3W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AM3G-1224SH30-NZ |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 125 mA |
| Efficiency | 81 % |
| Features | Remote On/Off |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 8-SIP Module |
| Power (Watts) | 3 W |
| Size / Dimension [x] | 22 mm |
| Size / Dimension [x] | 0.87 in |
| Size / Dimension [y] | 0.37 " |
| Size / Dimension [y] | 9.5 mm |
| Size / Dimension [z] | 0.47 " |
| Size / Dimension [z] | 12 mm |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 18 V |
| Voltage - Input (Min) [Min] | 9 V |
| Voltage - Isolation | 3000 V |
| Voltage - Output 1 | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
AM3G-1224 Series
Isolated Module DC DC Converter 1 Output 24V 125mA 9V - 18V Input
Documents
Technical documentation and resources
