Specification	6643271-1

Color	Black
Connector Style	Power
Connector Type	Male Pins, Plug
Contact Finish	Silver
Contact Finish Thickness	200 µin
Current Rating	35 A
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	1
Number of Positions Loaded	All
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-40 °C
Power Contacts (Typical)	1
Termination	Press-Fit
Voltage Rating	250 V

6643271 Series

Part	Material Flammability Rating	Voltage Rating	Operating Temperature (Min)	Operating Temperature (Max)	Current Rating	Number of Positions	Power Contacts (Typical)	Contact Finish Thickness	Number of Positions Loaded	Mounting Type	Color	Termination	Contact Finish	Connector Style	Connector Type
TE Connectivity AMP Connectors 6643271-1	UL94 V-0	250 V	-40 °C	105 °C	35 A	1	1	200 µin	All	Through Hole	Black	Press-Fit	Silver	Power	Male Pins Plug
