5140U1 0101000

Active

Belden Inc.

CABLE 2COND 14AWG BLACK

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 2COND 14AWG BLACK

Technical Specifications

Parameters and characteristics for this part

Specification	5140U1 0101000

Cable Type	Multi-Conductor
Conductor Insulation	Poly-Vinyl Chloride (PVC)
Conductor Material	Copper, Tinned
Features	Water-Blocked, UV Resistant
Jacket (Insulation) Diameter [diameter]	0.314 in
Jacket (Insulation) Diameter [diameter]	7.98 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	1.067 mm
Jacket (Insulation) Thickness	0.042 in
Jacket Color	Black
Length	1000 ft
Length	304.8 m
Number of Conductors	2
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-30 ░C
Usage	Sound, Security
Voltage	300 V
Wire Gauge	13.5 AWG

Part	Voltage	Jacket Color	Operating Temperature [Min]	Operating Temperature [Max]	Wire Gauge	Features	Number of Conductors	Conductor Insulation	Length	Length	Conductor Material	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Material	Cable Type	Usage
Belden Inc. 5140U1 0041000	300 V	Yellow	-30 ░C	105 ░C	13.5 AWG	UV Resistant Water-Blocked	2	Poly-Vinyl Chloride (PVC)	1000 ft	304.8 m	Copper Tinned	1.067 mm	0.042 in	0.314 in	7.98 mm	Poly-Vinyl Chloride (PVC)	Multi-Conductor	Security Sound
Belden Inc. 5140U1 0101000	300 V	Black	-30 ░C	105 ░C	13.5 AWG	UV Resistant Water-Blocked	2	Poly-Vinyl Chloride (PVC)	1000 ft	304.8 m	Copper Tinned	1.067 mm	0.042 in	0.314 in	7.98 mm	Poly-Vinyl Chloride (PVC)	Multi-Conductor	Security Sound

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 0.76

General part information

2 (1 Pair) Conductor Multi-Conductor Cable Black 14 AWG 1000.0' (304.8m)
