FN3025HP-30-71

Active

TE Connectivity Raychem Cable Protection

LINE FILTER 30A DIN RAIL

Search across all available documentation for this part.

Active

TE Connectivity Raychem Cable Protection

LINE FILTER 30A DIN RAIL

Technical Specifications

Parameters and characteristics for this part

Specification	FN3025HP-30-71

Applications	General Purpose
Approval Agency	CSA, ENEC, UR
Configuration	Single Stage
Current	30 A
Filter Type	Three Phase (Delta)
Frequency - Operating [Max]	60 Hz
Frequency - Operating [Min]	DC
Mounting Type	DIN Rail
Operating Temperature [custom]	100 °C, -25 °C
Termination Style	Terminal Block
Voltage - Rated AC (Phase to Ground/Neutral)	300 V
Voltage - Rated AC (Phase to Phase)	520 V

Part	Frequency - Operating [Max]	Frequency - Operating [Min]	Termination Style	Applications	Mounting Type	Operating Temperature [custom]	Approval Agency	Configuration	Voltage - Rated AC (Phase to Phase)	Filter Type	Current	Voltage - Rated AC (Phase to Ground/Neutral)
TE Connectivity Raychem Cable Protection FN3025HP-10-71	60 Hz	DC	Terminal Block	General Purpose	Chassis Mount	-25 °C 100 °C	CSA ENEC UR	Single Stage	520 V	Three Phase (Delta)	10 A	300 V
TE Connectivity Raychem Cable Protection FN3025HP-30-71	60 Hz	DC	Terminal Block	General Purpose	DIN Rail	-25 °C 100 °C	CSA ENEC UR	Single Stage	520 V	Three Phase (Delta)	30 A	300 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Three Phase (Delta) EMC/EMI Line Filter 30 A DC ~ 60Hz Single Stage Terminal Block
