CFM-A225-23-20

Active

CUI Devices

FAN AXIAL 120X25.4MM 24VDC WIRE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

CFM-A225-23-20

Active

CUI Devices

FAN AXIAL 120X25.4MM 24VDC WIRE

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	CFM-A225-23-20

Air Flow	3.55 m³/min
Air Flow	126.9 CFM
Approval Agency	cURus, CE, TUV
Bearing Type	Ball
Current Rating (Amps)	0.31 A
Fan Type	Tubeaxial
Features	Auto Restart, Speed Sensor (Tach)
Lifetime @ Temp.	70000 Hrs
Material - Blade	Polybutylene Terephthalate (PBT)
Noise	53.5 dB
Operating Temperature [Max]	70 °C
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-10 °C
Operating Temperature [Min]	-10 °C
Power (Watts)	9.36 W
RPM	4100 RPM
Size / Dimension [x]	120 mm
Size / Dimension [y]	120 mm
Static Pressure	122.1 Pa
Static Pressure	0.49 in H2O
Termination	3 Wire Leads
Voltage - Rated	24 VDC
Voltage Range [Max]	27.6 VDC
Voltage Range [Min]	16 VDC
Weight	0.417 lb
Weight	189.15 g
Width [y]	25.4 mm

CFM-A225 Series

Part	Size / Dimension [y]	Size / Dimension [x]	Noise	Voltage Range [Max]	Voltage Range [Min]	Bearing Type	Air Flow	Air Flow	RPM	Operating Temperature [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Static Pressure	Static Pressure	Current Rating (Amps)	Termination	Fan Type	Power (Watts)	Approval Agency	Lifetime @ Temp.	Material - Blade	Voltage - Rated	Features	Weight	Weight	Width [y]	Voltage - Rated [custom]
CUI Devices CFM-A225-13-10	120 mm	120 mm	53.5 dB	13.8 VDC	6 VDC	Ball	3.55 m³/min	126.9 CFM	4100 RPM	70 °C	70 °C	-10 °C	-10 °C	122.1 Pa	0.49 in H2O	590 mA	2 Wire Leads	Tubeaxial	9.48 W	CE cURus TUV	70000 Hrs	Polybutylene Terephthalate (PBT)	12 VDC	Auto Restart	0.419 lb	190.06 g	25.4 mm
CUI Devices CFM-A225V-231-445-11	120 mm	120 mm	44.5 dB	27.6 VDC	10 VDC		3.03 mł/min	108.2 CFM	3100 RPM	70 °C	70 °C	-10 °C	-10 °C	69.7 Pa	0.28 in H2O	0.238 A	3 Wire Leads	Tubeaxial	5.71 W	CE cURus TUV	70000 Hrs	Polybutylene Terephthalate (PBT)	24 VDC	Auto Restart	0.357 lb	161.93 g	25 mm
CUI Devices CFM-A225-13-22	120 mm	120 mm	53.5 dB	13.8 VDC	6 VDC	Ball	3.55 m³/min	126.9 CFM	4100 RPM	70 °C	70 °C	-10 °C	-10 °C	122.1 Pa	0.49 in H2O	590 mA	4 Wire Leads	Tubeaxial	9.48 W	CE cURus TUV	70000 Hrs	Polybutylene Terephthalate (PBT)	12 VDC	Auto Restart PWM Control Speed Sensor (Tach)	0.419 lb	190.06 g	25.4 mm
CUI Devices CFM-A225V-131-445	120 mm	120 mm	44.5 dB	13.2 VDC	4.5 V		3.03 mł/min	108.2 CFM	3100 RPM	70 °C	70 °C	-10 °C	-10 °C	69.7 Pa	0.28 in H2O	0.403 A	2 Wire Leads	Tubeaxial	4.84 W	CE cURus TUV	70000 Hrs	Polybutylene Terephthalate (PBT)	12 VDC	Auto Restart	0.359 lb	162.84 g	25 mm
CUI Devices CFM-A225-23-20	120 mm	120 mm	53.5 dB	27.6 VDC	16 VDC	Ball	3.55 m³/min	126.9 CFM	4100 RPM	70 °C	70 °C	-10 °C	-10 °C	122.1 Pa	0.49 in H2O	0.31 A	3 Wire Leads	Tubeaxial	9.36 W	CE cURus TUV	70000 Hrs	Polybutylene Terephthalate (PBT)	24 VDC	Auto Restart Speed Sensor (Tach)	0.417 lb	189.15 g	25.4 mm
CUI Devices CFM-A225-43-10	120 mm	120 mm	53.5 dB	55.2 VDC	30 VDC	Ball	3.55 m³/min	126.9 CFM	4100 RPM	70 °C	70 °C	-10 °C	-10 °C	122.1 Pa	0.49 in H2O	0.17 A	2 Wire Leads	Tubeaxial	11.04 W	CE cURus TUV	70000 Hrs	Polybutylene Terephthalate (PBT)		Auto Restart	0.42 lb	190.51 g	25.4 mm	48 VDC
CUI Devices CFM-A225V-122-340-20	120 mm	120 mm	34 dB(A)	13.8 VDC	4.5 V		2.1 m³/min	75 CFM	2200 RPM	70 °C	70 °C	-10 °C	-10 °C	40 Pa	0.16 in H2O	161 mA	3 Wire Leads	Tubeaxial	1.94 W	CE cURus TUV	70000 Hrs	Polybutylene Terephthalate (PBT)	12 VDC	Auto Restart Speed Sensor (Tach)	0.357 lb	161.93 g	25 mm
CUI Devices CFM-A225-23-11	120 mm	120 mm	53.5 dB	27.6 VDC	16 VDC	Ball	3.55 m³/min	126.9 CFM	4100 RPM	70 °C	70 °C	-10 °C	-10 °C	122.1 Pa	0.49 in H2O	0.31 A	3 Wire Leads	Tubeaxial	9.36 W	CE cURus TUV	70000 Hrs	Polybutylene Terephthalate (PBT)	24 VDC	Auto Restart Locked Rotor Sensor	0.417 lb	189.15 g	25.4 mm
CUI Devices CFM-A225V-127-405-20	120 mm	120 mm	40.5 dB(A)	13.8 VDC	4.5 V		2.6 m³/min	93 CFM	2700 RPM	70 °C	70 °C	-10 °C	-10 °C	54.8 Pa	0.22 in H2O	0.288 A	3 Wire Leads	Tubeaxial	3.46 W	CE cURus TUV	70000 Hrs	Polybutylene Terephthalate (PBT)	12 VDC	Auto Restart Speed Sensor (Tach)	0.357 lb	161.93 g	25 mm
CUI Devices CFM-A225V-231-445-20	120 mm	120 mm	44.5 dB	27.6 VDC	10 VDC		3.03 mł/min	108.2 CFM	3100 RPM	70 °C	70 °C	-10 °C	-10 °C	69.7 Pa	0.28 in H2O	0.238 A	3 Wire Leads	Tubeaxial	5.71 W	CE cURus TUV	70000 Hrs	Polybutylene Terephthalate (PBT)	24 VDC	Auto Restart Speed Sensor (Tach)	0.357 lb	161.93 g	25 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	1	$ 18.14
		10	$ 15.68

Description

General part information

CFM-A225 Series

Fan Tubeaxial 24VDC Square - 120mm L x 120mm H Ball 126.9 CFM (3.55m³/min) 3 Wire Leads
