DRP048V060W1BN

Active

Delta Electronics

AC/DC DIN RAIL SUPPLY 48V 60W

Search across all available documentation for this part.

Active

Delta Electronics

AC/DC DIN RAIL SUPPLY 48V 60W

Technical Specifications

Parameters and characteristics for this part

Specification	DRP048V060W1BN

AC Voltage - Input [Max]	264 VAC
AC Voltage - Input [Min]	85 VAC
Applications	ITE (Commercial)
Approval Agency	EN, CE, CB Scheme, EAC, CSA, SIQ, UL
Current - Output (Max) [Max]	1.25 A
Efficiency	92 %
Features	PFC, Universal Input, Load Sharing, Adjustable Output, IP20
Input Type	AC
Number of Outputs	1
Operating Temperature [Max]	80 ¯C
Operating Temperature [Min]	-25 °C
Size / Dimension [x]	4.92 in
Size / Dimension [x]	125 mm
Size / Dimension [y]	1.26 in
Size / Dimension [y]	32 mm
Size / Dimension [z]	4.76 "
Size / Dimension [z]	121 mm
Standard Number	61000-6-1, 62368-1, 61000-6-2, 50581, 61204-3, 55024, 60950-1, 61000-3-3, 107.1-01, 55011, 508, 55032, 61000-3-2
Voltage - Isolation	4000 V
Voltage - Output 1	48 V

Part	Features	Standard Number	Voltage - Isolation	Current - Output (Max) [Max]	Input Type	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Voltage - Output 1	AC Voltage - Input [Min]	AC Voltage - Input [Max]	Number of Outputs	Applications	Operating Temperature [Max]	Operating Temperature [Min]	Efficiency	Approval Agency	Size / Dimension [y]	Size / Dimension [z]
Delta Electronics DRP048V060W1BA	Adjustable Output IP20 Load Sharing PFC Universal Input	107.1-01 12.12.09 213 50581 508 55011 55024 55032 60079-15 60950-1 61000-3-2 61000-6-1 61000-6-2 61204-3 62368-1	4000 V	1.25 A	AC	1.26 in	4.76 "	121 mm	4.92 in	125 mm	32 mm	48 V	85 VAC	264 VAC	1	ITE (Commercial)	80 ¯C	-25 °C	92 %	ATEX EN CB Scheme CE CSA DNV GL EAC EN SIQ UL
Delta Electronics DRP048V060W1BN	Adjustable Output IP20 Load Sharing PFC Universal Input	107.1-01 50581 508 55011 55024 55032 60950-1 61000-3-2 61000-3-3 61000-6-1 61000-6-2 61204-3 62368-1	4000 V	1.25 A	AC	1.26 in	4.76 "	121 mm	4.92 in	125 mm	32 mm	48 V	85 VAC	264 VAC	1	ITE (Commercial)	80 ¯C	-25 °C	92 %	CB Scheme CE CSA EAC EN SIQ UL
Delta Electronics DRP048V120W1BN	Adjustable Output IP20 Load Sharing PFC Universal Input	107.1-01 50581 508 55011 55024 55032 60950-1 61000-3-2 61000-3-3 61000-6-2 61204-3 62368-1	4000 V	2.5 A	AC	1.97 "	4.76 "		4.85 "	123.1 mm		48 V	85 VAC	264 VAC	1	ITE (Commercial)	80 ¯C	-25 °C	91 %	CB Scheme CE CSA EAC EN SIQ UL	50 mm	121 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 40.52
