IL-312-A100SB-VFH05-A1-E3000

Obsolete

JAE Electronics

CONN RCPT 100POS SMD GOLD

Deep-Dive with AI

Search across all available documentation for this part.

IL-312-A100SB-VFH05-A1-E3000

Obsolete

JAE Electronics

CONN RCPT 100POS SMD GOLD

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	IL-312-A100SB-VFH05-A1-E3000

Connector Type	Receptacle, Outer Shroud Contacts
Contact Finish	Gold
Contact Finish Thickness	4 Áin
Contact Finish Thickness	0.1 Ám
Features	Solder Retention, Board Guide
Height Above Board [z]	0.104 in
Height Above Board [z]	2.65 mm
Mated Stacking Heights	3 mm, 3.5 mm
Mounting Type	Surface Mount
Number of Positions	100
Number of Rows	2
Pitch [x]	0.5 mm
Pitch [x]	0.02 in

IL-312-A Series

Part	Contact Finish	Mated Stacking Heights [z]	Contact Finish Thickness	Contact Finish Thickness	Height Above Board	Height Above Board	Pitch [x]	Pitch [x]	Connector Type	Number of Positions	Features	Number of Rows	Mounting Type	Height Above Board [z]	Height Above Board [z]	Mated Stacking Heights
JAE Electronics IL-312-A50S-VF-A1	Gold	2.5 mm 3 mm	4 Áin	0.1 Ám	0.087 in	2.2 mm	0.5 mm	0.02 in	Receptacle Outer Shroud Contacts	50	Solder Retention	2	Surface Mount
JAE Electronics IL-312-A60S-VF-A1	Gold	2.5 mm 3 mm	4 Áin	0.1 Ám	0.087 in	2.2 mm	0.5 mm	0.02 in	Receptacle Outer Shroud Contacts	60	Solder Retention	2	Surface Mount
JAE Electronics IL-312-A30S-VF-A1	Gold	2.5 mm 3 mm	4 Áin	0.1 Ám	0.085 in	2.16 mm	0.5 mm	0.02 in	Receptacle Outer Shroud Contacts	30	Solder Retention	2	Surface Mount
JAE Electronics IL-312-A40SB-VF-A1	Gold	2.5 mm 3 mm	4 Áin	0.1 Ám	0.087 in	2.2 mm	0.5 mm	0.02 in	Receptacle Outer Shroud Contacts	40	Board Guide Solder Retention	2	Surface Mount
JAE Electronics IL-312-A100SB-VFH05-A1	Gold		4 Áin	0.1 Ám			0.5 mm	0.02 in	Receptacle Outer Shroud Contacts	100	Board Guide Solder Retention	2	Surface Mount	0.104 in	2.65 mm	3 mm 3.5 mm
JAE Electronics IL-312-A100SB-VFH05-A1-E3000	Gold		4 Áin	0.1 Ám			0.5 mm	0.02 in	Receptacle Outer Shroud Contacts	100	Board Guide Solder Retention	2	Surface Mount	0.104 in	2.65 mm	3 mm 3.5 mm
JAE Electronics IL-312-A100S-VFH05-A1	Gold		4 Áin	0.1 Ám			0.5 mm	0.02 in	Receptacle Outer Shroud Contacts	100	Solder Retention	2	Surface Mount	0.104 in	2.65 mm	3 mm 3.5 mm
JAE Electronics IL-312-A50P-VF-A1	Gold	2.5 mm 3 mm	4 Áin	0.1 Ám			0.5 mm	0.02 in		50	Solder Retention	2	Surface Mount	0.061 "	1.55 mm
JAE Electronics IL-312-A40S-VF-A1	Gold	2.5 mm 3 mm	4 Áin	0.1 Ám	0.085 in	2.16 mm	0.5 mm	0.02 in	Receptacle Outer Shroud Contacts	40	Solder Retention	2	Surface Mount
JAE Electronics IL-312-A30S-VF-A1-E3500	Gold	2.5 mm 3 mm	4 Áin	0.1 Ám	0.085 in	2.16 mm	0.5 mm	0.02 in	Receptacle Outer Shroud Contacts	30	Solder Retention	2	Surface Mount

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

IL-312-A Series

100 Position Connector Receptacle, Outer Shroud Contacts Surface Mount Gold
