10117949-4050LF

Unknown

Amphenol ICC (FCI)

CABLE MINISAS HD 4X M-M 5M

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

10117949-4050LF

Unknown

Amphenol ICC (FCI)

CABLE MINISAS HD 4X M-M 5M

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	10117949-4050LF

Cable Connectors	miniSAS HD 4x
Cable Type	Round
Color	Black
Connector Type	Plug to Plug
Fastening Type	Latch Lock
Features	Pull Tab, Passive
Frequency - Max [Max]	12 Gbps
Gender	Male to Male
Number of Positions	36
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-40 °C
Shielding	Shielded
Usage	External
Wire Gauge	26 AWG

10117949 Series

Part	Features	Usage	Gender	Shielding	Cable Connectors	Cable Type	Color	Wire Gauge	Fastening Type	Operating Temperature [Min]	Operating Temperature [Max]	Frequency - Max [Max]	Number of Positions	Connector Type	Length [x]	Length [x]	Length	Length
Amphenol ICC (FCI) 10117949-4020LF	Passive Pull Tab	External	Male to Male	Shielded	miniSAS HD 4x	Round	Black	26 AWG	Latch Lock	-40 °C	80 C	12 Gbps	36	Plug to Plug	2 m	6.56 ft
Amphenol ICC (FCI) 10117949-4010LF		External	Male to Male	Shielded	miniSAS HD 4x	Round	Black	26 AWG	Latch Lock	-40 °C	80 C	12 Gbps	36	Plug to Plug	1 m	3.28 ft
Amphenol ICC (FCI) 10117949-4035HLF		External	Male to Male	Shielded	miniSAS HD 4x	Round	Black	26 AWG	Latch Lock	-40 °C	80 C	12 Gbps	36	Plug to Plug	3.5 m	11.48 '
Amphenol ICC (FCI) 10117949-4060HLF		External	Male to Male	Shielded	miniSAS HD 4x	Round	Black	26 AWG	Latch Lock	-40 °C	80 C	12 Gbps	36	Plug to Plug			19.69 ft	6 m
Amphenol ICC (FCI) 10117949-4050HLF		External	Male to Male	Shielded	miniSAS HD 4x	Round	Black	26 AWG	Latch Lock	-40 °C	80 C	12 Gbps	36	Plug to Plug
Amphenol ICC (FCI) 10117949-3020HLF		External	Male to Male	Shielded	miniSAS HD 4x	Round	Black	28 AWG	Latch Lock	-40 °C	80 C	12 Gbps	36	Plug to Plug	2 m	6.56 ft
Amphenol ICC (FCI) 10117949-4050LF	Passive Pull Tab	External	Male to Male	Shielded	miniSAS HD 4x	Round	Black	26 AWG	Latch Lock	-40 °C	80 C	12 Gbps	36	Plug to Plug
Amphenol ICC (FCI) 10117949-2015LF		External	Male to Male	Shielded	miniSAS HD 4x	Round	Black	30 AWG	Latch Lock	-40 °C	80 C	12 Gbps	36	Plug to Plug			4.92 '	1.5 m
Amphenol ICC (FCI) 10117949-2020LF	Passive Pull Tab	External	Male to Male	Shielded	miniSAS HD 4x	Round	Black	30 AWG	Latch Lock	-40 °C	80 C	12 Gbps	36	Plug to Plug	2 m	6.56 ft
Amphenol ICC (FCI) 10117949-5040HLF		External	Male to Male	Shielded	miniSAS HD 4x	Round	Black	24 AWG	Latch Lock	-40 °C	80 C	12 Gbps	36	Plug to Plug	4 m	13.12 ft

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

10117949 Series

36 Position miniSAS HD 4x Plug to Plug 16.40' (5.00m) Black Shielded
