1455A1002BK

Active

BLACK ALUMINUM WALL MOUNT EXTRUDED ENCLOSURE

Active

BLACK ALUMINUM WALL MOUNT EXTRUDED ENCLOSURE

Description

General part information

Box Aluminum Black End Panel(s) 3.976" L x 2.756" W (100.99mm x 70.00mm) X 0.472" (11.99mm)

Parameters and characteristics for this part

...

Part	Material	Type	Size / Dimension Length	Size / Dimension Width	Size / Dimension Height	For Use With/Related Products	Color	Weight	Features	Area (L x W)	Container Type	Thickness	Height	Design
Hammond Manufacturing 1455PPLRED-10	ABS	Bezel	5.079 in	1.344 in	0.413 in	1455P Series	Red
Hammond Manufacturing 1455JPLY	ABS	Bezel	3.194 in	1.186 in	0.354 in	1455J Series	Yellow
Hammond Manufacturing 1455A1002BK	Aluminum		3.976 in	2.756 in			Black	0.1 lb	Card Guides	11 in²	Box	0.06 in	0.472 in	End Panel(s)
Hammond Manufacturing 1455QPLY	ABS	Bezel	5.079 in	2.17 in	0.413 in	1455Q Series	Yellow
Hammond Manufacturing 1455LPLTRD-10	Polycarbonate (PC)	Bezel	4.178 in	1.324 in	0.354 in	1455L Series	Translucent - Red
Hammond Manufacturing 1455N1201BK	Aluminum		4.724 in	4.055 in			Black		Card Guides	19.2 in²	Box	0.06 in	2.087 in	End Panel(s)
Hammond Manufacturing 1455K1201BK	Aluminum		4.724 in	3.071 in			Black		Card Guides	14.5 in²	Box	0.06 in	1.693 in	End Panel(s)
Hammond Manufacturing 1455LPLBK	ABS	Bezel	4.178 in	1.324 in	0.354 in	1455L Series	Black
Hammond Manufacturing 1455D601BU	Aluminum		2.362 in	1.673 in			Blue		Card Guides	3.95 in²	Box	0.047 in	0.906 in	End Panel(s)
Hammond Manufacturing 1455D601RD	Aluminum		2.362 in	1.673 in			Red		Card Guides	3.95 in²	Box	0.047 in	0.906 in	End Panel(s)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources
