4052SQ-12(6)

Active

3M (TC)

TAPE DBL SIDED BLK 12"X12"

Search across all available documentation for this part.

Active

3M (TC)

TAPE DBL SIDED BLK 12"X12"

Technical Specifications

Parameters and characteristics for this part

Specification	4052SQ-12(6)

Adhesive	Acrylic, 100
Backing, Carrier	Polyurethane Foam
Color	Black
Length	12 "
Length	304.8 mm
Shelf Life	24 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature	70 °F
Storage/Refrigeration Temperature	21 °C
Tape Type	Double Coated, Double Sided
Temperature Range [Max]	38 °C
Temperature Range [Max]	100 °F
Temperature Range [Min]	21 °C
Temperature Range [Min]	70 °F
Thickness	0.03125 in
Thickness	31 mils
Thickness	0.031 in
Thickness	0.787 mm
Usage	Holding, Mounting, Joining
Width [x]	304.8 mm
Width [x]	12 in

Part	Thickness	Thickness	Thickness	Thickness	Shelf Life	Shelf Life Start	Color	Storage/Refrigeration Temperature	Storage/Refrigeration Temperature	Backing, Carrier	Length	Length	Length	Adhesive	Temperature Range [Max]	Temperature Range [Min]	Temperature Range [Max]	Temperature Range [Min]	Usage	Width [x]	Width [x]	Tape Type
3M (TC) 4052-12-5	0.03125 in	31 mils	0.031 in	0.787 mm	24 Months	Date of Manufacture	Black	70 °F	21 °C	Polyurethane Foam	4.6 m	15 ft	5 yd	Acrylic 100	38 °C	21 °C	100 °F	70 °F	Holding Joining Mounting	304.8 mm	12 in	Double Coated Double Sided
3M (TC) 4052SQ-12(6)	0.03125 in	31 mils	0.031 in	0.787 mm	24 Months	Date of Manufacture	Black	70 °F	21 °C	Polyurethane Foam	304.8 mm	12 "		Acrylic 100	38 °C	21 °C	100 °F	70 °F	Holding Joining Mounting	304.8 mm	12 in	Double Coated Double Sided
3M (TC) 4-5-4052B	0.03125 in	31 mils	0.031 in	0.787 mm	24 Months	Date of Manufacture	Black	70 °F	21 °C	Polyurethane Foam	4.6 m	15 ft	5 yd	Acrylic 100	38 °C	21 °C	100 °F	70 °F	Holding Joining Mounting	101.6 mm	4 "	Double Coated Double Sided
3M (TC) 4052-6-5	0.03125 in	31 mils	0.031 in	0.787 mm	24 Months	Date of Manufacture	Black	70 °F	21 °C	Polyurethane Foam	4.6 m	15 ft	5 yd	Acrylic 100	38 °C	21 °C	100 °F	70 °F	Holding Joining Mounting	152.4 mm	6 in	Double Coated Double Sided

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Double Coated, Double Sided Tape Acrylic, 100 Adhesive Black 12.00" (304.80mm) X 12.00" (304.80mm)

Technical documentation and resources
